SORG Vector Instructions For Use Manual page 45

5 Technical data
Vector BSA
Model: Vector BSA
Type: 791
Aid index no.: 18.50.03.1076
All measurements ± 5%
Designation
Seat width (SW)
in 20 mm/2 cm increments
Seat depth (SD)
in 20 mm/2 cm increments
Back height (BH)
in 25 mm/2.5 cm incre-
ments
Upper edge (UE) seat to
upper edge (UE) footrest
Back angle:
Lower leg length:
Armrest height
Seat angle
Frame length 1
Frame size 2
Frame size 3
Frame size XL
ETRTO wheel size 22"
ETRTO wheel size 24"
ETRTO wheel size 26"
Handrim size
Handrim size
Handrim size
Handrim diameter
Camber
Seat height (SH) front
Seat height (SH) front
Seat height (SH) rear
Seat height (SH) rear
Width wheelchair absolute
Length wheelchair absolute min.
Height wheelchair absolute with push handles
Permissible incline
Permissible downward
gradient
Resistance to tilting
Turn radius
Load (max.)/ weight test dummy
Empty weight fit for use
16.2 kg at:
Individual weights
Tyres
Usage life
Service life of the wheelchair
Normative requirements
2020-09-01
Dimensions
BSA frame 300-460 mm
BSA XL frame 300-460 mm
BSA frame 340-500 mm
BSA XL frame 440-500 mm
BSA frame 300-500 mm
BSA XL frame 300-500 mm
for footrest indoor 300-325 mm
installation with XL- 85-360 mm
frame for footrest 300-490 mm
external installation 355-520 mm
with XL-frame
80 -120 °
45 - 520 mm
170 - 300 mm
0 - 10°
484 mm
504 mm
559 mm
559 mm
Ø 25-451
Ø 25-489
Ø 28-590
at 22" (559mm) Ø 481 mm
at 24" (610mm) Ø 533 mm
at 26" (660mm) Ø 585 mm
Ø 19 mm
0°, 2°, 5°, 8°, 11°
min. 395 mm
max. 555 mm
min. 340 mm
max. 560 mm
min. SW + 200 mm
max. SW + 405 mm
min. 835 mm
max. max. 1065 mm
min. 750 mm
Standard XL max. 1120 mm
with push handles max. 1055 mm
height adjustable XL max. 1220 mm
12.3% = 7°
12.3% = 7°
12.3% = 7°
approx. 1000 mm dependent on the wheelchair size
120 kg
Frame SW/SD 46/50, driving wheels 24", casters 6" polyurethane, leg supports
continuous, seat and back cover, side guard
Driving wheels 1.2 - 2.2 kg
Leg supports 2 kg
Frame 8 kg
Conventional pneumatic tyres, sizes 1" or 1 3/8" or puncture proof tyres (same
dimensions), tyre pressure usually 3-10 bar
3 years
5 years
The wheelchair complies with the requirements of ISO 7176-8 and the require-
ments against ignition.
Instructions for use Vector & Vector BSA
Remarks
from any seat width 40 mm growable
from any seat width 40 mm growable
from any height max. 50 mm growable
The lower leg length is the distance
from: UE seat to UE footrest PLUS thick-
ness of the seat cushion.
depending on design
depending on design
depending on design
pure frame length
measured without push handles, firm
curved back plate, wheels or footrest
Conventional pneumatic tyres in sizes 1"
(25.4 mm), 1 3/8" (35 mm) - sizes
355 mm (20"), 451 mm (22"), 540 mm,
(24"). All puncture-proof tyres in the
specified dimensions.
Tube diameter
with drum brake wheels: 2°, 5°, 8°
The seat heights are measured from
the upper edge of the seat to the floor,
WITHOUT seat cushions!
For smallest or largest camber
With steering and pushing aid corre-
spondingly longer.
Depending on size and design
in case of non-excessive strain
45 of 48
