- Page 1 AIR PRESSURISED PAINT FEED AIR PRESSURISED PAINT FEED CONTAINER CONTAINER Model Nos: CPP5 • CPP11 • CPP30 • CPP40 OPERATING & MAINTENANCE INSTRUCTIONS 1106...
-
Page 2: Specifications
Please read these instructions carefully before using the Paint Pot Thank you for purchasing this CLARKE Air Pressurised Paint Feed Container. Before using the device, please read this manual thoroughly and carefully follow all instructions given. This is for your own safety and that of others around you, and is also to help you achieve long and trouble free service from your new product. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS ALWAYS keep the unit perfectly clean. This will not only prolong its life, but will also ensure you get the best results. NEVER exceed an air pressure supply of 3bar (43.5psi) to the product. NEVER attempt to adjust the safety valve NEVER tamper with the product or modify in any way, as this could prove to be dangerous and will invalidate the guarantee. - Page 4 This Paint Feed Container is designed primarily for use in spraying oil and solvent based paint. Clarke International provides a range of Spray Guns which may be used with these Feed Containers. Please see your local dealer for the HVLP and PRO Ranges.
-
Page 5: Method Of Operation
The paint should be agitated at regular intervals during use to ensure consistancy and avoid colour difference due to the paint settling.The CPP5 may be shaken gently. A typical configuration is shown in Fig.4. -
Page 6: Maintenance
Relief Valve replaced. PARTS & SERVICE CONTACTS For Spare Parts and Service, please contact your nearest dealer, or CLARKE International, on one of the following numbers. PARTS & SERVICE TEL: 020 8988 7400 PARTS & SERVICE FAX: 020 8558 3622 e-mail as follows: PARTS: Parts@clarkeinternational.com... - Page 7 Parts List & Diagram - CPP 5 No. Description Part No: No. Description Part No: Container KLCPP501 Fluid Outlet KLCPP512 Inner Container KLCPP501a Fluid Outlet Adapter 1 KLCPP513 Lid Assy. KLCPP502 Air Exhaust Valve KLCPP514 Handle KLCPP503 O-Ring KLCPP515 Gasket KLCPP504 Adapter KLCPP516...
- Page 8 Parts Diagram - CPP 11...
- Page 9 Parts List - CPP 11 No. Description Part No: No. Description Part No: Pressure gauge KLCPP1122 Container KLCPP1101 Pressure Relief Valve 1 KLCPP1129 Inner Container KLCPP1101a Adapter KLCPP1130 Lid Assy KLCPP1102 O-ring KLCPP1131 Gasket KLCPP1103 Air Exhaust Valve KLCPP1132 Bolt KLCPP1104 Agitating rod KLCPP1133...
- Page 10 Parts Diagram - CPP 30 & 40...
- Page 11 Parts List - CPP 30 & 40 No. Description Part No: No. Description Part No: Container CPP30 KLCPP3001 Connecting ring KLCPP3025 Container CPP40 KLCPP4001 O-ring KLCPP3026 Lid assembly KLCPP3002 Guide Bush KLCPP3027 Inner Container CPP30 1 KLCPP3003 Seal Ring KLCPP3028 Inner Container CPP40 1 KLCPP4003 Pressure Relief valve...
