- Page 1 ½ TONNE & 1 TONNE FOLDING CRANE ½ TONNE & 1 TONNE FOLDING CRANE MODELS CHC500DF & CHC1000DF PART No. 7610500 AND 7611002 OPERATION &MAINTENANCE INSTRUCTIONS 0502...
- Page 2 CLARKE GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase.
- Page 3 1000 2450mm IMPORTANT: If the load capacity decal becomes worn or illegible, contact Clarke International Spares Division, on 020 8558 6696 for replacement. Ensure that the equipment is correctly assembled, and that all the bolts and pins are in place and secure.
-
Page 4: Preparation For Use
Always inspect the crane before use to ensure it is in good condition, and replace any damaged or worn parts. 10. When replacing parts, use only those supplied by Clarke International. Refer to Parts List. 11. Ensure that the crane is properly maintained, and lubricated at all times, and that no rust or other forms of corrosion is allowed to weaken any part of the crane. -
Page 5: Operation
Lower the ram fully by unscrewing the large valve knob (Item B). With the ram in the fully retracted position, the oil should reach the level of the vent plug. Top up if necessary with Clarke hydraulic oil (part number 3050830). NOTE: We recommend that the hydraulic oil is changed after every 100 hours of operation. -
Page 6: Parts List
Parts List Item Description CHC 500 DF CHC 1000 DF Part No. Part No. Mast with Base CHC5001 CHC10001 Main Jib CHC5004 CHC10004 Jib Extension CHC5005 CHC10005 Ram Assembly CHC5007 CHC10007 Right Leg CHC5003 CHC10003 Left Leg CHC5002 CHC10002 Pivoting Wheel Kit CHC5010 CHC10010 Fixed Roller Kit... - Page 7 1/2 Tonne & 1 Tonne Folding Crane...
-
Page 8: Parts List Cont
Parts List Cont Item Description CHC 500 DF CHC 1000 DF Part No. Part No. CHR5031 CHR10031 Gasket Kit CHR5032 CHR10032 Ram Guide Bush CHR5033 CHR10033 Compression Cylinder CHR5034 CHR10034 Oil Reservoir CHR5035 CHR10035 Cylinder Head CHR5036 CHR10036 Locking Ring Nut CHR5037 CHR10037 Ball ¼”... - Page 9 Hydraulic Ram...
