Astralpool Control Basic Plus Installation Manual page 11

Status (*only read)
Alarms (*only read)
Alarm (Latch)
0000138174
low byte
hi byte
low byte
hi byte
0x20
.bit 0
.bit 1
.bit 2
.bit 3
.bit 4
.bit 5
.bit 6
.bit 7
.bit 8
.bit 9
.bit 10
.bit 11
.bit 12
rev.1.1
0x00
.bit 0 Alarm flag (one or more alarms are presents)
Function Mode
0 = pH
.bit 1
1 = ORP
Not used
.bit 2
Control Mode Status:
.bit 3
0/1 = System Stopped/Running
.bit 4 Not used
.bit 5 Not used
.bit 6 Not used
.bit 7 Not used
.bit 8 0 : Normal Operation Mode
.bit 9 1 : Calibration mode
2: Programming mode
3: Logging Mode
.bit 10 RFU (Reserved Future Use)
.bit 11 RFU (Reserved Future Use)
.bit 12 Not used
.bit 13 Not used
.bit 14 Not used
.bit 15 Not used
0x01 See Note 2
.bit 0 Reserved
.bit 1 pH OFA
.bit 2 ORP OFA
.bit 3 Level
.bit 4 Flow
.bit 5 RFU (Reserved Future Use)
.bit 6 RFU (Reserved Future Use)
.bit 7 RFU (Reserved Future Use)
.bit 8 RFU (Reserved Future Use)
.bit 9 RFU (Reserved Future Use)
.bit 10 RFU (Reserved Future Use)
.bit 11 RFU (Reserved Future Use)
.bit 12 RFU (Reserved Future Use)
.bit 13 RFU (Reserved Future Use)
.bit 14 RFU (Reserved Future Use)
.bit 15 Communication Watchdog
See Note 2
low byte Reserved
pH OFA
ORP OFA
Level
Flow
RFU (Reserved Future Use)
RFU (Reserved Future Use)
RFU (Reserved Future Use)
hi byte RFU (Reserved Future Use)
RFU (Reserved Future Use)
RFU (Reserved Future Use)
RFU (Reserved Future Use)
RFU (Reserved Future Use)
