Laser Safety
2.3

Laser Class 3R

The sensors with the /3R option fall within laser class 3R. The laser is operated on a pulsed mode, the maximum optical power is
≤ 30 mW resp. ≤ 50 mW. The pulse frequency depends on the adjusted measuring rate (0 ... 25 kHz). The pulse duration can be 7 µs
up to infinite.
i
Observe the laser protection regulations.
Laser radiation. Close your eyes or immediately turn away if the laser beam hits the eye. Irritation or injury of the
eyes possible.
Accordingly, the following applies: The accessible laser radiation is harmful to the eyes. Looking directly into the laser beam is harmful
to the eyes with laser class 3R devices. Reflections of shiny or mirroring surfaces are also harmful to the eyes.
Class 3R laser sensors require a laser protection officer.
Attach the following warning labels to the cover (front and rear side) of the sensor housing:
LASER RADIATION
AVOID DIRECT EYE EXPOSURE
CLASS 3R LASER PRODUCT
IEC 60825-1: 2014
P ≤ 30mW, P ≤ 30mW; E ≤ 18mW/cm²;
0
λ = 658nm; F = 0...25kHz, t = 7µs...∞
LLT30xx-25, LLT30xx-50,
In addition, the following information label must be attached to the laser output on the sensor housing:
LASER
APERTURE
scanCONTROL 30xx
P
LLT30xx-100, LLT30xx-200
LASER RADIATION
AVOID DIRECT EYE EXPOSURE
CLASS 3R LASER PRODUCT
IEC 60825-1: 2014
P ≤ 50 mW , P ≤ 50 mW; E ≤ 30 mW/cm²;
0 P
λ = 658nm; F = 0...25kHz, t = 7µs...∞
COMPLIES WITH 21 CFR 1040.10 AND 1040.11
EXCEPT FOR CONFORMANCE WITH
IEC 60825-1 ED. 3., AS DESCRIBED IN
LASER NOTICE NO. 56, DATED MAY 8, 2019
Only for USA
