ETC Setup Guide
Response MIDI Gateway Setup Guide
Connect to USB MIDI from the Eos Host
To connect to your MIDI Gateway from the Eos Host, you must enable USB MIDI. For additional information
on using MIDI with an Eos console, refer to the
1:
Connect the USB from your MIDI Gateway to your Eos console.
2:
On your console, navigate to Setup > System > Show Control > MIDI.
3:
From the Device Settings section, set USB MIDI to Enabled.
Note:
Connect to your MIDI Gateway Over the Network
1:
Connect an Ethernet cable to the Ethernet port on you MIDI gateway and then connect the cable to
a network switch on your Eos console's lighting network.
2:
If the port on the switch is not PoE, you can use the USB port to power the gateway.
3:
On your console, navigate to Setup > System > Show Control > MIDI.
4:
Ensure that the parameter values set for Network MIDI Rx Source ID and MIDI Tx Source ID on your
console are also set for the Source IDs for your MIDI gateway:
• On your MIDI Gateway, press the Check Mark button to bring up the menu
• Navigate to Setup > Source IDs > (available range is 1-32)
Response MIDI Gateway
You can also enable USB MIDI on your console from ECU > Local I/O.
Eos Family Operations Manual
Network MIDI Rx Source ID and
MIDI Tx Source ID
Page 3 of 5
.
Set to Enabled
