ETC Unison AV/Serial Interface v1.1.0 Quick Manual page 9

Q u i c k G u i d e :
Unison AV/Serial Interface v1.1.0 Quick Guide
"Disconnect" refers to the Unison processor's status (as named in the Unison menus)
and binding refers directly to the station's status.
You connect/disconnect the AV/Serial Interface station from the Unison processor in the
same manner as any other Unison station. (Arch>Setup>Stations>Connect|Disconnect)
From the AV/Serial Interface station, you type Escape. That clears all bindings for the
station.
Changing the Station Type
This process, while simple to do, must be done in the following order for consistently
correct results.
Step 1:
Step 2:
Step 3:
Addit ional Notes & Commen ts
Single-Byte Co mmands
Object
Backspace
Cancel
Xon
Xoff
Escape
Clear
ACK
NAK
• The Cancel command flushes command buffer and cancels Xoff command.
•
•
•
• The Escape command clears bindings, takes station to disconnected state, and sends a
service pin message.
• The Help command is only enabled if the echo is enabled.
• The Clear command clears the key and fader LED values to off and sets the levels to 0.
• To speed things up, set commands intentionally do not have a reply. If you want be sure the
state was changed, use a get command after the set.
• White space is ignored except when used as command part separator.
• A period(.) is the suggested character to separate command parts but can also be a space,
tab, dash (-), colon(:), at (@) or slash (/).
• Except as indicated, characters below 0x20 (SPACE) and above 0x7F (DEL) will be
discarded.
• All input values default to 0 at reset. A host PC will respond to the reset status bit to update
values as needed.
Uni son AV/ Se r ia l I nt er f ac e v1 .1 . 0 Qui ck Gui de
If the AV/Serial Interface station is bound to the Unison processor, manually
disconnect the station at the Unison processor. (Arch>Setup>Stations>Disconnect)
Send the ST command with the station type you want it to become. Sending the ST
command also executes an Escape command at the station to unbind the station
and send a service pin message. (See
Connect the AV/Serial Interface station at the Unison processor.
(Arch>Setup>Stations>Connect) The station may connect automatically if there is
only single station of that type in the Unison configuration.
Command Use
^H (0x08) Removes the last character from the buffer
^C (0x03) Cancels the current command
^S (0x13) Resumes data reception
^Q (0x11) Pauses data reception
^[ (0x1B) Unbind station
^Z (0x1A) Clear values
^F (0x06) Valid packet received (in Packet Mode only)
^U (0x15) Invalid packet received (in Packet Mode only)
SF0 only clears all faders.
SR0 only clears all rates.
SB0 only clears all buttons.
Station Type (st) on page
Pa ge 9 of 10
8)
