SmartPack User Interface

The SmartPack family user interface and menu structure provide users an intuitive easy setup with multiple language

options built-in.

Use the Standby/Control power switch to start up and shut down operation of the SmartPack. When the breaker is in the

"On" position, the blue Power LED is illuminated indicating the power is on.

WARNING:

When the Standby/Control power switch is in the "Off" position, the unit is still connected to the

power supply. When working on exposed load circuit wiring the load cables must be unplugged or

the unit disconnected from the power supply.

The green DMX LED indicates a DMX signal. When no DMX signal is present, the green LED will flash. When a stable

DMX control signal is present the green LED will illuminate fully.

The display is a high contrast 20-character by two line backlit LCD. The control symbol, indicated in the top right corner

of the LCD, indicates the current control source.

https://support.etcconnect.com/ETC/Power_Controls/Smart_Family/SmartPack_and_SmartSwitch/SmartPack_User_Manual/...

Updated: Tue, 14 Sep 2021 15:42:05 GMT

Table of Contents

Do you have a question about the SmartPack and is the answer not in the manual?

Page 1 The SmartPack family user interface and menu structure provide users an intuitive easy setup with multiple language options built-in. Use the Standby/Control power switch to start up and shut down operation of the SmartPack. When the breaker is in the “On” position, the blue Power LED is illuminated indicating the power is on.
Page 2 Press and hold << and use the + and - buttons to adjust the contrast of the LCD display. Initial Power Up Display The first time you apply power to the SmartPack you will be asked to choose a language for the operating system. The language options will cycle through the following four options at three second intervals.
Page 3 Each circuit has a dedicated, three-position switch that sets the circuit to Dimmable, Relay, or Hot Power (constant circuit). ThruPower Switch (CE only) Each circuit has a dedicated, two-position switch that sets the circuit to Dimmable or Hot Power (constant circuit). https://support.etcconnect.com/ETC/Power_Controls/Smart_Family/SmartPack_and_SmartSwitch/SmartPack_User_Manual/… Updated: Tue, 14 Sep 2021 15:42:05 GMT Powered by...
