ETC Unison AV/Serial Interface v1.1.0 Quick Manual page 6

Q u i c k G u i d e :
LED States (ld) [Read Only]
0
1
2
3
4
Level (ll)
ll
Fade Rat e (rr.dd )
rr
dd
Pr otocol Ver sion (pv)
pv
Station Status (ss)
nn
1
2
3
4
5
6
7
8
Uni son AV/ Se r ia l I nt er f ac e v1 .1 . 0 Qui ck Gui de
Unison AV/Serial Interface v1.1.0 Quick Guide
= Off
= On
= On dim
= Blink slow
= Blink fast
= 0-255 (default) [or 0-100]
Notes:
• At reset, fader levels are set to 0 unless saved to memory.
• The level scale (0-255 or 0-100) is set in Configuration Settings, index 3.
• Level defaults to a scale of 0-255
= 0-300 seconds [0 or 0.0 = disable rate (default)]
= 0-9 tenths of a second
Notes:
• Defaults to disable rate (0)
= Software version of the Serial Button Protocol
Notes:
• The version is Hex encoded where the high byte is the major release and
the low byte is the minor release.
- index
Hex encoded value, 4 characters (i.e. 0x0010 = installed but unbound / 0x0020 = installed & bound)
Bit Description
0 Station reset occurred
1 Station wink occurred
2 A command error occurred
3 UART error occurred
4,5 Unison install status (00 = unistalled, 01 = installed, 10 = bound)
6-15 Unused
Neuron ID string
Button binding
Button LED binding
Fader LED binding
Fader binding (Hex encoded bit pattern)
Level binding (Hex encoded bit pattern)
Node number
Notes:
• If the "echo" configuration flag is set, the update reply is suppressed and a question mark (?)
followed by the bad command is sent.
• If the "no update" configuration flag is set, bits 0 thru 3 will be clear bits when status is read.
Otherwise, these will always be read as 0.
• Indexes 3 thru 7 indicate the state of virtual object bindings to the Unison Control Module.
Non-zero bindings (for a type that does not support an object) may indicate a mismatch in
binding/connection of the station. Rebinding via service pin and reconnecting at the Control
Module face panel may be necessary (i.e. if type is 100 and fader LED binding equals 1,
there is a binding/connection mismatch).
