Managing individual FortiGate-7000F FIMs and FPMs
FortiGate-7000F special management port numbers (slot numbers in order as installed in the chassis)
Slot Number
11
9
7
5
3
1
2
4
6
8
10
12
For example, to connect to the GUI of the FIM in slot 2 using HTTPS you would browse to https://192.168.1.99:44302.
To verify which FIM or FPM you have logged into, the GUI header banner and the CLI prompt shows its hostname. The
System Information dashboard widget also shows the host name and serial number. The CLI prompt also shows the slot
address in the format <hostname> [<slot address>] #.
Logging in to different FIMs or FPMs allows you to use dashboard widgets, FortiView, or Monitor GUI pages to view the
activity of that FIM or FPM. Even though you can log in to different modules, you can only make configuration changes
from the primary FIM; which is usually the FIM in slot 1.

HA mode special management port numbers

In HA mode, you use the same special port numbers to connect to FIMs and FPMs in chassis 1 (chassis ID = 1) and
different special port numbers to connect to FIMs and FPMs in chassis 2 (chassis ID = 2):
FortiGate-7000F HA special management port numbers
Chassis and Slot Address
Slot Number
Ch1 slot 11 FPM11
Ch1 slot 9 FPM09
Ch1 slot 7 FPM07
FortiGate-7121F System Guide
Slot Address HTTP
(80)
FPM11 8011
FPM09 8009
FPM07 8007
FPM05 8005
FPM03 8003
FIM01 8001
FIM02 8002
FPM04 8004
FPM06 8006
FPM08 8008
FPM10 8010
FPM12 8012
HTTP
(80)
8011
8009
8007
HTTPS (443) Telnet
(23)
44311 2311
44309 2309
44307 2307
44305 2305
44303 2303
44301 2301
44302 2302
44304 2304
44306 2306
44308 2308
44310 2310
44312 2312
HTTPS (443) Telnet
(23)
44311 2311
44309 2309
44307 2307
Fortinet Technologies Inc.
SSH (22) SNMP (161)
2211 16111
2209 16109
2207 16107
2205 16105
2203 16103
2201 16101
2202 16102
2204 16104
2206 16106
2208 16108
2210 16110
2212 16112
SSH (22) SNMP (161)
2211 16111
2209 16109
2207 16107
