Bristol torbex shower base

BRISTOL TORBEX SHOWER BASE

Dimensions are nominal measurements only.

SPECIFICATIONS

Recommended Use

Material

Dimensions

Waste Outlet

Cleaning RECOMMENDATIONS

We recommend the use of soapy water or approved cleaners.

This product should not be cleaned with abrasive materials.

Damage caused by any improper treatment is not covered by the product warranty- refer to Warranty Conditions.

Disclaimer: Products in this specification manual must by regulation be installed by

licensed and registered trade people. The manufacturer/distributor reserves the right to vary

specifications or delete models from their range without prior notification. Dimensions are

nominal measurements only. Dimensions and set-outs listed are correct at time of publication

however the manufacturer/distributor takes no responsibility for printing errors.

Tech Page Version 1

Domestic, hotel and commercial

Torbex High Strength Composite

900mm x 900mm x 29mm

1200mm x 900mm x 29mm

1370mm x 900mm x 31mm

1660mm x 900mm x 31mm

Centre Rear

To see the complete BRISTOL range go to

www.reece.com.au/bathrooms

page 1 of 5

Table of Contents

Do you have a question about the posh and is the answer not in the manual?

Page 1 1660mm x 900mm x 31mm Waste Outlet Centre Rear To see the complete BRISTOL range go to www.reece.com.au/bathrooms CLEANING RECOMMENDATIONS We recommend the use of soapy water or approved cleaners. This product should not be cleaned with abrasive materials. Damage caused by any improper treatment is not covered by the product warranty- refer to Warranty Conditions.
Page 2 page 2 of 5 BRISTOL TORBEX SHOWER BASE Ø Detail A Scale 0.75:1 Ø Detail A Scale 0.75:1 1200 Plumbers, please ensure a copy of the installation instructions is left with the end user for future reference...
Page 3 page 3 of 5 BRISTOL TORBEX SHOWER BASE Ø Detail A Scale 0.75:1 1370 Ø Detail A 1660 Scale 0.75:1...
Page 4 12mm notched trowel to ensure the base is fully supported. Cement based tile adhesive must be left to cure before installing the Posh Bristol shower base. 3. It is essential to test for water run off to the waste outlet prior to commencing the installation of the shower walls.
Page 5 5 of 5 BRISTOL TORBEX SHOWER BASE POSH BRISTOL TORBEX SHOWER BASE FITTING INSTRUCTIONS FOR POSH BRISTOL WASTE OUTLETS Cover Silicone Ring Apply silicone in this Apply a small amount of area to the fill the gap silicone on this surface between the outlet and the shower base.
