Installation Instructions
Hideaway+ Sensor Button / Plate Inwall Black
Installation
100-240V
50-60Hz
0-1500mm
1000mm
0
1
Note:
Any electrical work connected on this project must be installed by qualified personnel,
in accordane with AS/NZS 3000 Wiring Rules.
Please ensure a copy of the installation
instructions is left with the end user for future reference
Published 10/06/2020
