Eaton Crouse-Hinds SynergEX EZFlex Series Installation & Maintenance Information page 8

Aux./Trip Contact – Branch and On-Chassis Main (available as optional)
Rated Voltage
Rated Current
Minimum Switching Capacity
The technical data relates to standard built-in apparatus. If other built-in apparatus is used, the technical data
sheets or the data on the type label shall be observed.
277/480V Circuit Breakers – Off-Chassis Main
Rated Voltage
Rated Current
Types
Rated Switching Capacity
Component Size
Weight
Aux./Trip Contact – Main (available as optional)
Rated Voltage
Rated Current
The technical data relates to standard built-in apparatus. If other built-in apparatus is used, the technical data
sheets or the data on the type label shall be observed.
All statements, technical information and recommendations contained herein are based on information and tests we believe to be reliable. The accuracy or completeness
thereof are not guaranteed. In accordance with Eaton's Crouse-Hinds Division's "Terms and Conditions of Sale," and since conditions of use are outside our control,
the purchaser should determine the suitability of the product for his intended use and assumes all risk and liability whatsoever in connection therewith.
to 230 VAC 277 VAC 480 VAC
2A 2A 1A
5 mA at 24V
Main contact Up to 277/480 VAC, 60 Hz
Main contact 50-225A
3-pole GHG627...R...
10 kA
3-pole
10.5 kg
Up to 480 VAC
5A
Spacing Chart for Myers Hubs
Eaton's Crouse-Hinds Division
1201 Wolf Street, Syracuse, New York 13208 • U.S.A.
Copyright 2020, Eaton
©
IF 1911
Revision 1
New 09/20
