Eaton Crouse-Hinds SynergEX EZFlex Series Installation & Maintenance Information page 7

DIMENSIONAL DRAWINGS: BREAKERS
IF 1911 • 09/20
5.20" (132mm)
4.49" (114mm)
0.98" (25mm)
4.02" (102mm)
1.42" (36mm)
1-pole 277 VAC
5.20" (132mm)
4.49" (114mm)
2.40" (61mm)
4.02" (102mm)
2.83" (72mm)
3-pole 277 VAC/480 VAC
5.20" (132mm)
4.49" (114mm)
X 1.69" (43mm)
160
12.5
6.3" (160mm)
4.02" (102mm)
N N 1/2 2 3/4 4 5/6
6
N
N 2/1 1 4/3 3 6/5 6
2.13" (54mm)
203
7 .99" (203mm)
Main Breaker 277 VAC/480 VAC
X 3.82" (97mm)
Figure 8 – Breaker Dimensional Drawings
4.25" (108mm)
Copyright
2-pole; EPD and GFI 1-pole
180
7 .1" (180mm)
0.49" (12.5mm)
205.3
8.08" (205.3mm)
5.20" (132mm)
4.49" (114mm)
4.02" (102mm)
2020, Eaton's Crouse-Hinds Division
©
5.20" (132mm)
4.49" (114mm)
1.69" (43mm)
4.02" (102mm)
2.13" (54mm)
277 VAC/480 VAC
5.20" (132mm)
4.49" (114mm)
X 2.40" (61mm)
4.02" (102mm)
2.83" (72mm)
Page 7
