- Page 1 DF6100, DF61002 Installation and Operation Manual Power Power Fault System FIRE Fault General TEST Fault Sounder General Disable Disable Fault 0786 G211013 DoP0228 EN54-2:1997 + A1:2006 EN54-4:1997 + A1:2002 + A2:2006...
-
Page 2: Table Of Contents
Faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40 INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... - Page 3 Configure zones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76 INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com...
- Page 4 Technical I/O Unit Wiring (CFC301) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .107 INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com...
- Page 5 THIS DOCUMENT SHALL NOT BECOME PART OF OR MODIFY ANY CONTRACT BETWEEN THE PARTIES . In no event will Eaton be responsible to the purchaser or user in contract, in tort (including negligence), strict liability or other-wise for any special, indirect, incidental...
- Page 6 That is why we offer you so many ways to get the support you need . Whether it is by phone, fax, or email, you can access Eaton’s support information 24 hours a day, seven days a week . Our wide range of services is listed below . You should contact your local distributor for product pricing, availability, ordering, expediting and repairs .
- Page 7 RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE . DISPOSE OF THE USED BATTERIES ACCORDING TO THE INSTRUCTIONS . This product must only be disposed of in accordance with the WEEE directive . INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com...
-
Page 8: Section 1: System Installation And Design
Fire panel/repeater panels to be installed and terminated . System to be powered up by installer and auto learn mode activated (see Auto Learn section) . System to be tested and verified by installer, prior to final commissioning . INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 9: System Design Guidelines
5 . Final commissioning Minimum 2 weeks notice is required from receipt of Address Schedule and Commission request form . Eaton Lighting Service Engineer to attend site implement/ oversee the final commissioning procedures (see Commissioning section), in conjunction with the installer . -
Page 10: Compatible Equipment
88H x 147W x 57D MSU840 Addressable Shop Unit Monitor 88H x 147W x 57D CSI350 Addressable Spur Isolator 88H x 147W x 57D CMIO353 Addressable Mains Relay 130H x 180W x 60D INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 11: Equipment Compatibility
Equipment compatibility Sensors Loop wired sensors must be of the Eaton soft addressed analogue type . Eaton conventional detectors can be connected via a Zone Monitor Unit or Shop Unit interface . The connection of other detector types via a Zone Monitor Unit or Shop... - Page 12 . Relay circuits There are Relay circuits built-in the standard Panel . Additional relays can be added to the system by using Eaton soft addressing, Single Channel or 3 Channel Input/ Output Units . Relays/Auto-dialers and auxiliary equipment...
-
Page 13: System Overview
. For initial configuration or major system changes special PC configuration software is available enabling Eaton Lighting and Security personnel to do this more efficiently than can be achieved using the system screen . - Page 14 Similarly if a device is removed, the relevant address is saved as a spare address for future use, the addresses of the remaining devices are not altered . Multiple languages The Panel supports a large number of languages as standard . INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com...
-
Page 15: Technical Specification
: 1 .5 Amp Sounder Circuit Fuses (F1/2) : 1 .6 Amp (Quick Blow) End of line device : 210Ω + Diode AUX 1 Max Load : 1 Amp Fused (PTC2) : 1 .1A polyswitch INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... - Page 16 Flammability Rating : UL 94 V0 Total Number of knockouts : 11 Diameter of Knock out : 20mm TERMINAL BLOCKS : DO NOT USE EXCESSIVE FORCE WHEN TIGHTENING THE SCREWS ON THE TERMINAL BLOCK INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com...
-
Page 17: Optional Functions As Per En54 P2&4
The Panel has the facility to inhibit the operation of the output sounders, Output to Fire routing equipment and the output of the fire protecting equipment until one more confirmatory signals are received from different zones . This feature is programmable using Site Installer Software . INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... - Page 18 7. Loop feeds and returns should never be used within the same cable . Cable resistance Core diameter Typical FP200 resistance 1.0mm² 18.1 Ohms/km/Core 1.5mm² 12.1 Ohms/km/Core 2.5mm² 7.41 Ohms/km/Core 4.0mm² 4.61 Ohms/km/Core INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com...
-
Page 19: Installation
. INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... - Page 20 Do not touch the electronics directly . Mounting the Backbox The Panel can be surface mounted and recessed . To surface mount; drill three holes and fix the backbox to the wall using suitable screw fixings . INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com...
-
Page 21: External Connections
. An additional warning label should be provided, depending on whether:- INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 22: Networking
When operating as a networked system all fire and fault event information is displayed at every panel, silencing and resetting of alarms can also be carried out from any panel on a networked system if panels are suitably configured . INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 23: Input/Outputs
. If the short circuit is not removed the alarms will not cancel . WARNING No voltage should be applied to this input . Switch/Contactor timer etc. (Apply NO voltage) INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... - Page 24 . Please ensure that all equipments connected to this output will only draw current when a fire condition exists . WARNING Do not exceed the rated output current . INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com...
-
Page 25: Maintainance
. Special equipment is required for cleaning smoke detectors . Every 5 years Replace sealed lead acid battery . Cleaning: When cleaning the panel, use a moist cloth . Do not use solvents or harsh abrasives . INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 26: Section 2: Commissioning
. This facility can be accessed via the engineering menu and can be switched on or off at any time as required . INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... - Page 27 Null Modem Cable Fault System A.serial Output FIRE Fault General TEST Fault Sounder General Disable Disable Fault B. USB Output USB Convertor Serial Rs232 port can be locatated on the main board INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com...
-
Page 28: Panel Fault Finding
= S/C Normal O/C Fire = 12V No Fault 0V (short CCT) Fault = -O.6V-No Fire 24V Fire = 28V (Open Circuit, No Input) REPEAT FOR LOOP 2 = 22V (Device Fitted) 0V (Unused) INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 29: Pc Comissioning Software
Non-Latching-> device won’t latch in alarm condition, used in conjunction with isolates . Day / night Devices affected : Optical-Heat -> mode changes between heat or optoheat mode Heat -> mode changes between Heat A1R and Heat CS INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 30: Device Outputs
This option is a manual intervention override, when enabled (check in box) the delay can be overridden from any call point on the loop when triggered . Daynight See coincidence detection below . INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 31: Panel Outputs
. When the ‘coincidence’ box is checked - the ‘Allocate device’ button allows the user to populate this list . INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 32: Section 3: Panel Controls & Indicators
Report fault to service dept System fault Monitors fire panel for faults Report fault to service dept Test Supervisor/engineer is testing the systems Report to system supervisor Sounder Indicates the sounder status Check with system supervisor INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 33: Touch Screen Display
. When displaying the system menu on the Touch Screen, the last 5 lines of the display are shown in reverse text . INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 34: Panel Operation
Meeting Room 1, Building 1, 1st floor First Fire Loop: 1, Zone: 2, Type: Optical System Healthy 10 Zones Active Print All Help Total Fires= 1 Tuesday dd-mm-yyyy Tuesday dd-mm-yyyy 16:25.25 16:25.25 BST On BST On INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 35: Public Access Level 1
Lp: 1, Ad: 4, Z: 1, Opto/thermal [69] 005 12:35:59 Fault! : Device5 005 03-Jun-03 12:51 Warning! : Device5 Lp: 1, Ad: 4, Z: 1, Opto/thermal [69] Lp: 1, Ad: 5, Z: 1, Opto/thermal [69] INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 36: Evacuate (Access Level 2)
Faults Disabled View Fires View Pre AC = 0 Alarms Select “Yes” to evacuate the building . This will activate ALL sounders and activate all panel relays Do you wish to continue? INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 37: Silence Alarms
Faults AC = 0 View Alarms Disabled Zone: 0 Addresses: 0 Touch button to View list Select “yes” to silence Alarm . This will silence ALL sounders Do you wish to continue? INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 38: Mute Buzzer
View Alarms View Do you want to continue? Disabled Faults 14:22:49 Mains Failure Faults = Short circuits, broken detectors etc. To remove faults from this list: 1) Fix Fault 2) Reset Panel INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 39: Pre-Alarms
View list The individual buttons show which devices and the number of devices which have been disabled . Press one of the buttons to display detailed information for a particular category . INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 40: Faults
Buzzer Fires AC = 0 View Pre Alarms View View Disabled Others Faults Enable/Disable Weekly Test Send Log to PC Print View Log Check Config Lamp test Send analogue values to PC INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 41: Enable/Disable
003 Device 3, Zone 1 Disable Loop:1, Zone: 1, Type: Opto/thermal 004 Device 4, Zone 1 Enabled Loop:1, Zone: 1, Type: Opto/thermal 005 Device 5, Zone 1 Disable Loop:1, Zone:1, Type: Opto/thermal INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... - Page 42 Reset FRE Off Alarms Buzzer Print All Log Records Print Fire Log Print Last 10 Log Records Print Fault Log Print Disablements Print Test Log Print Current Faults Print Current Fires Exit INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com...
-
Page 43: Lamp Test
Enter the Supervisor Mode and Select the “Others” Tab . Press “Lamp Test” . Lamp Test Lamp Test LED’s will light in numerical order LED’s will light in numerical order Cancel Cancel INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 44: Weekly Test
Awaiting Alarm Signal Weekly test Do you want to continue? Will reset after 4 minutes Cancel The panel will automatically return to the system healthy screen once the weekly test has been completed . INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 45: Installation Instructions For: Single Channel Input Unit Mcim-C
1. Only connect cable screen to its adjacent earth terminal. 2. The end of line resistor provided must always be fitted, even if the input is unused. 3. Monitored inputs can detect open or short circuit faults. INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... - Page 46 – IN terminal and the – OUT terminal . The isolator operates in conjunction with Eaton Analogue Addressable Control Panels when a low parallel resistance fault of typically 200? is present between the +VE and –VE of the loop wiring .
-
Page 47: Viewing Events
. Once the maximum 1000 events has been reached Panel will automatically overwrite the oldest event every time a new event is stored . The event log can only be reset by an approved service engineer . INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 48: Check Auto Config
Send analogue values to PC Supervisor FRE Off Check Auto Config Replace Device Exit Supervisor FRE Off Press the Supervisor Mode button at the top left Check of the Auto Config screen. INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 49: Replace Device
Send analogue values to PC Supervisor FRE Off Check Auto Config Replace Device Exit Supervisor Supervisor FRE Off FRE Off Enter Loop 1 Address Select a Loop Loop 1 Loop 2 Exit Exit INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 50: Test Device (Access Level 3)
One Man Walk Test 004 Meeting Room 1, Building 1, 1st floor Loop: 1, Zone: 2, Type: Optical Test Device Test Device Loop 1, Address: A Loop 1, Address: A Previous Done INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 51: Test Zone
Touch "Test" Button to remove a zone from test mode Zone 001 Building 1, Ground Test Zone 002 Building 1, 1st floor Zone 003 Building 1, 2nd floor Zone 004 Packing & Stores Zone 005 Building 2, basement INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 52: Sounder Level Test Mode
One Man Walk Test Sound Level Test Mode Do you want to continue? Sound Level Test Mode All sounders will now pulse 15 seconds on, 30 seconds off Touch “Stop” button to stop test Stop INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 53: Global Flashing Led On/Off
Test Device Test Zone Select “Global Flashing LED On/ Sound Level Test Mode Off” from the Test Menu Screen . Global Flashing LED On/Off One Man Walk Test Global flashing LED on/of Flashing INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 54: One Man Walk Test
Menu Screen . One Man Walk Test Global Flashing LED On/Off Feature is outside EN54 spec One Man Walk Test One Man Walk Test Do you want to continue? Awaiting Alarm Signal Stop INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 55: Commission: Load Cdr From Laptop
Italian Mode Load CDR from Laptop This will erase the current CDR Do you want to continue? Important: Do not click “Retrieve Database From Panel” pressing “Yes” on the “Load CDR” screen . INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 56: Commission: Download Cdr To Laptop
Screen Cover Press "OK" to continue or "Cancel" to exit Load logo from PC Italian Mode Cancel Download CDR to Laptop Start PC program Press "OK" to continue or "Cancel" to exit Cancel INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 57: Commission: Auto Learn
Yes - autolearn all loops Load logo from PC Italian Mode Pre-addressed auto-learn Supervisor Exit Auto Learn Yes - autolearn all loops FRE Off Do you want to continue? Pre-addressed auto-learn Yes - autolearn all loops INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 58: Erase Log
System Detail Screen Cover Load logo from PC Italian Mode This will delete all log entries Do you want to continue This will delete all log entries Do you want to continue INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 59: System Details
Page 3 Page 4 Page 5 Service Print Exit Reset FRE off Loop 1 Loop 2 Hybrid (ZMU) 4~20mA Outpu Input Hybrid Page 1 Page 2 Page 3 Page 4 Page 5 INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 60: Load Logo From Pc
Configure Menu Screen . Auto Learn Change Panel Number Number of Panels Erase Log and Reset in Network System Detail Screen Cover Load logo from PC Italian Mode Load logo from PC Exit INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 61: Analogue Level
Enter Address ....4 5 6 Loop 1 0 - 13 Loop 2 0 - 0 7 8 9 Loop 3 0 - 0 Loop 4 0 - 0 ok 0 Cancel INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 62: Change Panel Number
Download CDR to Laptop Printer Settings Auto Learn Change Panel Number Number of Panels Erase Log and Reset in Network System Detail Screen Cover Load logo from PC Italian Mode Change Panel Number ......Cancel INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 63: Number Of Panels In Network
Printer Settings Auto Learn Change Panel Number Number of Panels Erase Log and Reset in Network System Detail Screen Cover Load logo from PC Italian Mode Number of Panels in Network ......Cancel INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 64: Screen Cover
Auto Learn Change Panel Number Number of Panels Erase Log and Reset in Network System Detail Screen Cover Load logo from PC Italian Mode Service Exit Reset FRE Off Installed Not Required INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 65: Italian Mode
Erase Log and Reset in Network System Detail Screen Cover Load logo from PC Italian Mode Service Exit Reset FRE off Italian Mode T1:Call Point Delay 0 mins,0 secs T2:Detector Delay 0 mins Enabled Disabled INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 66: Programming I/O And Sounders T1
70 secs 80 secs 90 secs 100 secs 110 secs 120 secs T1/T2 Callpoint Overide T1/T2 scope 130 secs 140 secs 150 secs 160 secs 170 secs 180 secs Auto -enable Delays Exit INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 67: Programming I/O And Sounders T2
70 secs 80 secs 90 secs 100 secs 110 secs 120 secs T1/T2 Callpoint Overide T1/T2 scope 130 secs 140 secs 150 secs 160 secs 170 secs 180 secs Auto -enable Delays Exit INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 68: Programming I/O And Sounders. Panel Outputs
Change User Code Mute Service Exit Reset FRE Off Buzzer Press panel outputs - NOTE Interface Inputs/ Interface Outputs are only used in certain Panel Outputs export markets . Auxiliary Board Alarm Verification Features INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 69: Programming I/O And Sounders. Auxiliary Board
Configure Heat Detectors Auxillary Board Alarm Verification Feature Change Text Network FRE double-knock override Configure Zones Language Day/Night Change Pascode Sounder tone Network Protocal Not Required Extinguisher Fire Bridgsde Australian Swedish Mode INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 70: Programming I/O And Sounders Alarm Verification
Configure Heat Detectors Auxillary Board Alarm Verification Feature Change Text Network FRE double-knock override Configure Zone Language Sounder tone Day/Night Change Pascode Service Exit Reset FRE off AVF On/Off AVF length AVF Zones INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 71: Sound Settings
Volume become the global Medium settings for High all loop Sound sounders . Service Service Exit Reset Exit Reset FRE off FRE off Volume Slow Woop Two Tone Sound Continuous INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 72: Change Date/Time
Set the Time Using the Buttons Shown Below . Service Sync with Cancel Reset FRE Off Master Current Time: Hour Mins Mins 10:16:12 Hour Mins Mins BST On Month Year Current Date: Wednesday Month Year dd-mmm-yyyy INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 73: Change Zone Text
....................................Zone 001 Zone 1 Zone 002 Zone 2 Zone 003 Zone 3 Zone 004 Zone 4 CAPS OTHER SPACE CANCEL INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 74: Change Text
Loop: 1, Zone: 1, Type : Opto/thermal 004 Device 4, Zone 1 CAPS Loop: 1, Zone: 1, Type : Opto/thermal 005 Device 5, Zone 1 OTHER SPACE CANCEL Loop: 1, Zone: 1, Type : Opto/thermal INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 75: Change Panel Text
Change address text Change zone text Change zone text Change Panel Text Change Panel Text Correct Panel Text Correct Panel Text CF1100 ..................CF1100 ..................CAPS OTHER SPACE CANCEL CAPS OTHER SPACE CANCEL INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 76: Configure Zones
Touch the dash to move the device into 004 Device 4, Zone 2 the selected zone. Loop: 1, Zone: 2, Type : Opto/thermal 005 Device 5, Zone 2 Loop: 1, Zone: 2, Type : Opto/thermal INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 77: Change Passcode
............ok 0 Cancel Passcode is not correct. Verification is incorrect New Password accepted No change made No change made Saved INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 78: Add Zone
Sounders Change Date/Time Configure Heat Detectors Change Text Network Language Configure Zones Day/Night Change Password Service Exit Reset FRE Off Add Zone Delete Zone Add Device Delete Device Add Zone ? INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 79: Delete Zone
Zone 003 Zone 3 Zone 001 Zone 1 Delete Zone 2? Zone 004 Zone 4 Zone 002 Zone 2 Zone 003 Zone 3 Zone 004 Zone 4 Delete Zone 2? Delete Zone 2? INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 80: Add Device
Confirm New Device and Loop . Exit Loop 1 Loop 2 Service Reset FRE Off Loop 1 Loop 2 Loop 2 Exit Scanning Loop Exit Exit Loop 2 Scanning Loop Loop 2 Exit Scanning Loop Exit INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 81: Delete Device
005 Device 5, Zone 1 Loop: 1, Zone: 1, Type : Opto/thermal Delete Device 3? Device 3 Loop1, Address 3, Device Type Opto/thermal Delete Device 3? Device 3 Loop1, Address 3, Device Type Opto/thermal INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 82: Configure Heat Detectors
Loop: 1, Zone: 2, Type : Opto/thermal 005 Device 5, Zone 1 Loop: 1, Zone: 1, Type : Opto/thermal Select appropriate detector class . Service Exit Reset FRE Off Thermal A1R Thermal BS Thermal CS Exit INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 83: Network Filter
Select Group of Panels or Panel on the same network Network Fire Fault Network Network Pre-Alarm Select if Network is required to be on/off . Service FRE off Reset Not Required Evacuate Network Silence Network Fire Network Fault Network Pre-Alarm Network INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 84: Network Filter
Sounders Change Date/Time Configure Heat Detectors Change Text Network Language Configure Zones Day/Night Change Password Service Silence Mute Evacuate Reset FRE off Alarms Buzzer Exit Network filter Receive message over Netrwork INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 85: Language
Change Pascode Select required Language English Français Deutsch Nederlands Italiano Português Nederlands (BE) Cesky Dansk Slovensky Magyar Slovenski Hrvatski Lietuva Svenska Russian Greek Viê · t Eesti Afrikaans Suomi Türkçe Arabic Polski Latviešu INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 86: Day/Night
Configure Heat Detectors Configure Zones Language Change Text Network Change Pascode Day/Night Configure Zones Language Change Pascode Day/Night Delay (minutes) Delay (minutes) Exit Feature is outside En54 spec Exit Feature is outside En54 spec INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 87: Password Protection
. Press supervisor mode and the password entry screen will be displayed, type in the passcode and press Ok . If the wrong password is entered three times further access to the system is denied . INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 88: Section 4: Appendix
Section 4: Appendix Section 4: Appendix System wiring INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 89: Detector Base Wiring (Cab300)
E E a a r r t t h h s s c c r r e e e e n n o o f f c c a a b b l l e e t t o o b b e e c c o o n n t t i i n n u u o o u u s s b b e e t t w w e e e e n n s s e e n n s s o o r r s s INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 90: Call Point Wiring (Cbg370S/Cbg370Wp)
Two tone 610 / 910Hz @ 1Hz cycle Slow whoop 500-1200Hz in 3.5 seconds / 0.5secs gap S S + + F F + + Due to restricted access space, do not use excessive cable in this area. INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 91: Loop Powered Beacon Wiring (Cab382)
. Earth screen must be continuous along entire length of loop . Analogue Addressable Loop ote: Care should be taken to ensure the cable does not put stress on the circuit board INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 92: Ip66 Wall Sounder Wiring (Cas381Wp, Casb383-Wp)
A A n n a a l l o o g g u u e e A A d d d d r r e e s s s s a a b b l l e e L L o o o o p p INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 93: Base Sounder Vad (Casbb394)
Base terminal 1, 2, 3 and 4 not used . All wiring terminates as shown above . ote: WARNING Do NOT use high voltage testers if ANY equipment is connected to the system . Earth screen must be continuous along entire length of loop . INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 94: Wall Sounder Vad (Casb393)
2 . Soft addressed . Standard connections WARNING Do NOT use high voltage testers if ANY equipment is connected to the system . Earth screen must be continuous along entire length of loop . INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 95: Ip66 Wall Sounder Vad (Casb393Wp)
2 . Soft addressed . Standard connections WARNING Do NOT use high voltage testers if ANY equipment is connected to the system . Earth screen must be continuous along entire length of loop . INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 96: Way Input Output Unit (Cio351, Cio351S, Cio351Sst)
2 . The end of line resistor must always be fitted, even if the inputs are unused 3 . Monitored inputs can detect open or short circuit faults 4 . Output relays are volt-free contacts and are not monitored INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 97: Channel Mains Rated I/O Unit Wiring (Cmio353)
I I N N P P U U T T ote: 1 . Only connect cable screen to its adjacent earth terminal 2 . The end of line resistor must always be fitted, even if the spur is unused INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 98: Zone Monitor Unit Wiring (Czmu352)
4 . Maximum spur length - See BS5839 Pt1:2002 for Zone Coverage 5 . Maximum number of call points allowed is unlimited 6 . Detector zone end of line device is EOLM-1 (supplied) 7 . Callpoint zone has end of line resistor INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 99: Intrinsically Safe Zone Monitor Unit Wiring (Czmu352-Is)
3 . Only connect cable screen to its adjacent earth terminal 4 . The end of line resistor must always be fitted, even if the spur is unused 5 . Maximum spur length – See BS5839 Pt1:2001 for Zone Coverage INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 100: Shop Monitor Unit Wiring (Msu840)
4 . Maximum spur length - See BS5839 Pt1:2002 for Zone Coverage 5 . Maximum number of call points allowed is unlimited 6 . Detector zone end of line device is EOLM-1 7 . Callpoint zone has end of line resistor INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 101: Spur Isolator Wiring (Csi350)
1 . Only connect cable screen to its adjacent earth terminal 2 . For maximum spur length / load see BS5839 Pt1:2002 3 . This unit can only be used with Eaton CAB300 and CDB300/I Sensor bases and compatible sensors... -
Page 102: Way Sounder Controller Wiring (Csc354Cpr)
B B A A T T T T E E R R Y Y ote: 1 . Only connect cable screen to its adjacent earth terminal 2 . The end of line resistors must always be fitted, even if the sounder circuits are unused INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 103: 4-20Ma Interface Wiring (Cgi420, Cit420, Cgi420R, Cit420R)
Recommended Loop Cable Type: FIRETUF , FP200, MICC No addressing of the interface is required . See control panel operation for details . There are no serviceable parts so no maintenance procedures apply INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 104: Micro Zone Monitor Module Wiring (Miu872)
CIU872 Standard connections ote: 1 . This unit can only be used with Eaton FXN520 detector base and compatible detectors 2 . Only connect cable screen to its adjacent earth terminal 3 . The end of line resistor must always be fitted, even if the spur is unused 4 . -
Page 105: Micro Input Module Wiring (Mcim)
1 . Only connect cable screen to its adjacent earth terminal 2 . The end of line resistor provided must always be fitted, even if the input is unused 3 . Monitored inputs can detect open or short circuit faults INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 106: Micro Output Module Wiring
Loop In- EARTH Earth Loop Out+ Loop Out- MCOM Earth ote: 1 . Only connect cable screen to its adjacent earth terminal 2 . Output relay are volt-free contacts and are not monitored INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... -
Page 107: Technical I/O Unit Wiring (Cfc301)
This unit will take 2 addresses, one for input and one for output . There are no serviceable parts so no maintenance procedures apply Standard connections ANALOGUE ADDRESSABLE LOOP OUTPUTS INPUTS LOOP R elay 2 R elay 3 R elay 1 INSTALLATION AND OPERATION MANUAL 25-16328-B November 2020 www.eaton.com... - Page 108 Eaton Electrical Systems Ltd . Wheatley Hall Road Doncaster South Yorkshire DN2 4NB Eaton EMEA Headquarters Route de la Longeraie 7 1110 Morges, Switzerland Eaton .eu © 2019 Eaton Eaton is a registered trademark. All Rights Reserved Publication No . 25-16328-B...
