- Page 1 NPWT PRO and PRO to GO PATIENT USER MANUAL...
- Page 3 • Keep the Cardinal Health™ NPWT PRO family device turned on at all times unless there is bleeding from the wound or instructed by your Healthcare Professional. • Do not change the settings on the Cardinal Health™ NPWT PRO family device unless you are told to do so by your Healthcare Professional.
- Page 4 CAUTION: This Cardinal Health™ NPWT PRO / PRO to GO (herein after referred to as the Cardinal Health™ NPWT PRO family of devices) PATIENT User Manual is not a guarantee or warranty. It is intended only as an operational guide.
-
Page 5: Table Of Contents
1.5 Safety Tips ................................5 2. Introduction to the Cardinal Health™ NPWT PRO Family of Devices ................6 2.1 Getting to know the Cardinal Health™ NPWT PRO Family of Devices ..............6 2.2 Charging the Battery .............................. 7 3. Operating Instructions..............................8 3.1 Power ON/OFF ................................ -
Page 6: Introduction
The Cardinal Health™ NPWT PRO/PRO to GO systems are intended for patients with chronic, acute, traumatic, subacute and dehisced wounds, partial-thickness burns, ulcers (such as diabetic or pressure), flaps and grafts. The Cardinal Health™ NPWT PRO/PRO to GO systems are intended for use in acute, extended and home care settings. 1.2 Contraindications The Cardinal Health™... -
Page 7: Safety Tips
KEEP THERAPY ON The Cardinal Health™ NPWT PRO family of devices should be operated at least 22 hours out of every 24 hour period. Contact your Healthcare Professional if therapy stops or if the device is OFF for more than 2 hours in a 24 hour period. -
Page 8: Introduction To The Cardinal Health™ Npwt Pro Family Of Devices
You may not need to use many of the buttons on the device, but it is important that you are familiar with what they are and their location (see Figure 1). NOTE: The Cardinal Health™ NPWT PRO family device will be virtually silent during normal operation with a well-sealed dressing. -
Page 9: Charging The Battery
2.2 Charging the Battery The Cardinal Health™ NPWT PRO family of devices has an internal battery that provides up to 24 hours of operation from a single full-charge. When the battery is running low, an alarm will sound to let you know you must plug in the device to charge the battery. -
Page 10: Operating Instructions
3. Upon turning ON the device, the dressing should slowly collapse indicating the presence of suction. 4. The Cardinal Health™ NPWT PRO family of devices should be operated at least 22 hours out of every 24 hour period. Contact your Healthcare Professional if the device is OFF for more than 2 hours in a 24 hour period. Your dressing must be changed. - Page 11 • Press the canister release button above the Two-tone beep. canister and slide the full canister out. Cap and If the Cardinal Health™ PRO family of devices are dispose of properly. Slide new canister in, align placed on its front, fluid entering the canister will the short ports and click into place.
-
Page 12: Care And Cleaning
Supplies immediately. A.C. Adapters are available from Cardinal Health. WARNING: The Cardinal Health™ NPWT PRO family of devices should only be used with the supplied A.C. Adapter. Use of an incorrectly rated adapter could create a shock hazard for the patient or caregiver and/or severely damage the device. -
Page 13: Specifications
5. Specifications Cardinal Health™ NPWT PRO family of devices Dimensions ......................6 x 4.3 x 2.75 in. (19.3 x 11.0 x 7.0 cm) Weight ...............................0.9 Lbs (0.43Kg) Therapy Settings ........................50, 75, 100, 125, 150 mmHg Canister Volume ...............................300cc/500cc With respect to electric shock, fire, and mechanical hazards, conforms to IEC60601-1. -
Page 14: Symbols
5.1 Explanation of Symbols Authorized Representative in the European Union Consult Instructions for Use Manufacturer Power ON/MUTE Date of Manufacture Power OFF Adjustment Button. UP. Expiry Date Adjustment Button. DOWN. Lot/Batch Number Continuos/Intermittent Catalog Number A.C. Power Status Serial Number Battery Charge Status Storage Conditions Class II, Internally... -
Page 15: Electromagnetic Compatibility
5.2 Electromagnetic Compatibility The Cardinal Health™ NPWT PRO family of devices conforms to all pertinent requirements of IEC 60601-1-2. The EMC summary tables are provided herein below for your reference. Guidance and Manufacturer’s Declaration: Electromagnetic Emissions (IEC 60601-1-2) Emissions Test... - Page 16 Guidance and Manufacturer’s Declaration: Electromagnetic Immunity (IEC 60601-1-2) IEC 60601 Compliance Level Immunity Test Electromagnetic Environment Test Level Guidance Electrostatic discharge ±6 kV contact ±6 kV contact Floor should be wood, concrete, or ceramic tile. If floors are covered with (ESD) IEC 61000-4-2 ±8 kV air ±8 kV air...
-
Page 17: Replacement Parts
Cardinal Health™ SensiSkin™ Drape (10 per pkg.) ....................47-7100 NOTE: In order to assure the highest safety, quality and efficacy of the products, the Cardinal Health™ NPWT PRO family of devices should only be used with the Cardinal Health™ disposables, and Cardinal Health™ NPWT Dressings should... -
Page 18: Questions & Information
7. Questions & Information For questions, comments or additional information pertaining to the Cardinal Health™ NPWT PRO family of devices, please contact your local Cardinal Health representative, or: Call our customer support professionals at 1.866.484.6798 Cardinal Health Waukegan, IL 60085 www.cardinalhealth.com... - Page 20 Rev. B 2017-07 cardinalhealth.com Cat. 6708888, 47-0010 © 2017 Cardinal Health. All Rights Reserved. CARDINAL HEALTH, the Cardinal Health LOGO, SENSISKIN and SPEEDCONNECT are trademarks or registered trademarks of Cardinal Health and may be registered in the US and/or in other countries.
