Cardinal Health NPWT PRO Clinician Quick Reference Manual

Cardinal Health™ NPWT PRO / PRO to GO
Clinician Quick Reference Guide
Power ON / MUTE
Alarm Condition Display
Power / Charging Status
NOTE: Please refer to the Cardinal Health™ NPWT PRO / PRO to GO / PRO at HOME Clinician
User Manual for detailed instructions and review the Precautions and Contraindications
before use.
Insert Canister
Insert canister in holder by sliding it up into bottom back side of device. Line up the two
short ports with the receptacle and press until it "clicks" into place and locks. To remove
canister, press canister release button located above canister viewing window, grasp
canister at bottom and pull downward.
Connect the Dressing
Connect the blue end of the SpeedConnect™ tubing to the open port of the canister.
Gently twist and push connector on just enough to seal it. Make sure that the clamp on
the SpeedConnect™ tubing is open. NOTE: Please refer to the Cardinal Health™ NPWT PRO /
PRO to GO Clinician User Manual for instructions on how to properly dress the wound and
troubleshoot issues.
Turning the Device ON
Press the ON button to start therapy. Select desired Pressure Setting by pressing the
UP or DOWN
Therapy Lockout
To lock therapy setting, press and hold the ON
beep three times indicating therapy setting is locked. Repeat process to unlock therapy setting.
Pressure Setting
button for three seconds. The device will
Canister Release
Power OFF
Continuous / Intermittent (Variable) Mode
Battery Charging Port
Intermittent (Variable) Mode
To operate the device in intermittent mode, press the INTERMITTENT MODE
An amber light will indicate the device is operating in intermittent mode. Repeat process
to return to continuous mode.
Adjust Alarm Volume
Volume may be adjusted by pressing and holding the ON
UP or DOWN arrow button. The numbers 1-5 will appear in the display. 1 is the
lowest, 5 is the highest volume level.
Troubleshooting Alarms
If the device begins to alarm, refer to the troubleshooting table on the back to identify and
correct the alarm condition.
Turning the Device OFF
button.
For questions or information, contact Cardinal Health Canada
at 1.800.268.7916
Notice to Users: As with any prescription medical device, failure to
follow product instructions or adjusting settings and performing therapy
applications without the express direction and/or supervision of your
trained clinical caregiver may lead to improper product performance and
the potential for serious or fatal injury.
the area of dressing placement. Failure to remove the dressing may inhibit
electrical current transmission and/or patient resuscitation.
button.
button and tapping the
Magnetic Resonance Imaging (MRI):
The Cardinal Health™ NPWT PRO family of devices is not MRI-compatible. Do
not take into the MRI area.
Hyperbaric Oxygen Therapy (HBO): NEVER allow a device—whether on or
patient prior to HBO treatment.
