- Page 1 Evento Timber Suites To Suit: Arteon 10003SL & 12503SL Fires Instructions for Installation R1 DEC 2020 200805_1...
- Page 2 Contents Technical Specs Contents of Fixings Box Installation – Timber 5 – 8 Maintenance 200805_1...
-
Page 3: Technical Specification
Technical Specification Dimensions (mm) Fire Surround Logs 54” EVENTO ARTEON PRYZM TIMBER FLOOR 1270 1370 5D 1000 3SL STANDING 64” EVENTO ARTEON PRYZM TIMBER FLOOR 1520 1620 5D 1250 3SL STANDING Visible Glass Area (mm) Fire ARTEON PRYZM 5D 1000 3SL ARTEON PRYZM 1245 5D 1250 3SL... - Page 4 Amp Switched Fused spur or 3 Amp 3 Pin Plug if using a double socket. Fly Lead 830mm Fly Lead- Required to connect the LED Lights to the Fire. Please ensure all fixings are present before commencing installation. If anything is missing please call Customer Services on 01914300901 or email us at customerservices@bemodern.co.uk 200805_1...
- Page 5 Installation – Timber Note: The surround and fire are a two adult person lift. A second person will be required to lift and support the surround and fire during installation. Before the surround can be installed, consideration will need to be given routing the power supply to the fire. This will affect the stages of the installation process.
- Page 6 Installation – Timber continued Note: Ensure the glass and cardboard boxes inside the fire have been removed before proceeding further, this will reduce the handling weight. Lift the Fire into the cut out in the Assembled Base, ensuring the Fire is sitting on the two central supports. See Diagram 4.
- Page 7 Downlights to the mains cable, checking that the lights and sensor are working correctly. If there are any problems please call Customer Services on 01914300901 or email us at customerservices@bemodern.co.uk Diagram 11 200805_1...
- Page 8 Installation – Timber continued Lift the Assembled Top into position. Note: The Assembled Top is a two adult person lift. Note: Great care must be taken to avoid crushing or damaging the Downlight cables during installation. See Diagram 12. Diagram 12 Ensure the Assembled Top is centralized on the Metal Sides, before fixing in position.
-
Page 9: Maintenance
CAUTION: Abrasive cleaners should not be used on the glass panel. Liquids should not be sprayed directly onto any surface of the unit. Troubleshooting Should you have any queries regarding this product please contact Customer Services on 01914300901 or email us at customerservices@bemodern.co.uk Recycling All cardboard packaging is recyclable. IMPORTANT NOTE: Wall fixings (i.e.
