temperature deviates within the range of the set
hysteresis, the fan speed will adjust in proportion to the
idle speed.
Example
The set minimum fan speed is 40%.
The maximum fan speed is 100%.
The set temperature is 27 °C.
The hysteresis is 2 °C.
In this case, the idle speed is 70% (100% - 40% = 60%
range, divided by 2 gives the distance to the exact
middle: 30%). The idle speed lies in the exact middle of
40% and 100%, therefore at 70% (100% minus 30%).
If the measured temperature is equal to the set
temperature of 27 °C, the fan runs at idle speed, so at
70%.
The temperature can fall or rise within the set hysteresis
range of -/+ 2 °C. The fan speed will then decrease or
increase by 15% per degree. After all, the range is 60%,
divided by a range of 4 (- 2 °C and + 2 °C). So if the
temperature drops by one degree to 26 °C, the fan
speed will decrease by 15% in proportion to the idle
speed, and therefore decrease to 55% (70% minus 15%).
If the measured value is 28 °C, the fan speed increases
by 15% in proportion to the idle speed. The fan speed
becomes 85%. If the measured value rises to 29 °C, the
speed increases again by 15% to the maximum fan
speed.
Min Max Idle
40% 100% 70%
20% 100% 60%
15% 100% 57,5%

5. Fuse replacement

If a short circuit occurs due to fan overload, the fuse will
blow. Even if the Clima Eco Temp/Humidity Fan Control
does not operate at all, in the worst case, this could
indicate a blown fuse. To replace the fuse you have to
open the Clima Eco Temp/Humidity Fan Control.
Complete the following steps:
1. Remove the plug from the socket.
2. Open the housing by unscrewing the 4 screws on
the back of the Clima Eco Temp/Humidity Fan
Control.
3. Locate the fuse and remove it.
4. Insert a new 5 amp fuse.
5. Screw the 4 screws to close the housing.
____________________________________________________________________________________________________________________________
TechGrow | Innovative Growing Solutions
Hys +/- per
1 °C
2 °C 15%
2 °C 20%
2 °C 21,25%
Your Clima Eco Temp/Humidity Fan Control is ready for
use again.
