Leckey Mygo Stander User Manual page 28

p28 Mygo Stander User Manual
11.8 ADJUSTING
THE STANDARD,
COMPLEX AND
FLIPAWAY CHEST
LATERAL SUPPORTS
To adjust the height and angle of
the lateral supports, loosen the Allen
bolt , adjust to the required width,
height and angle and retighten
securely.
Complex laterals
The complex laterals can also be
angled to allow the pad to contour
to the user's shape. To adjust loosen
the screw at the centre of the pad,
angle the pad to the required position
and retighten the screw. The laterals
can be flipped away to aid transfer,
by pulling the pin
rotating the support out of the way.
at the back and
11.9 SHOULDER
SUPPORT
To adjust the angle of the shoulder
support laterals, loosen the Allen bolt
screw , move laterals to required
angle and retighten.
