Leckey Mygo Stander User Manual page 25

11.3.2 ATTACHING
THE EXTENDED KNEE
BRACKETS
Loosen Knob
support. Slide extension bracket unto
the knee bracket and secure with
white rubber washer, silver washer,
plastic spacer and knob.
Fix the knee supports to the extension
brackets at the required height using
black rubber washer, black washer
and M6 screw.
and remove knee
Mygo Stander User Manual p25
11.4 ADJUSTMENT
TO ACCOMMODATE
THE CONTRACTURE
ANGLE
If possible, adjustment of the
swinging footplate on the Mygo
Stander should be performed when
the client is out of the stander.
However there may be circumstances
where it is necessary or preferable
to adjust the angle of the swinging
footplate with the client in the
stander. This process requires two
competent persons; one to make
the adjustments and one to assess
the comfort of the client during the
adjustment, and is best performed
with the stander in a horizontal
position.
In upright or prone standing:
Assess the client's range of
movement, muscle tone, etc, on a
plinth and determine the optimum
standing posture before positioning
the client in the stander. Position the
client in the Mygo Stander. While
carefully supporting the head and
shoulders, move the client into a
horizontal position. Open the knee
