English
Check the path of the belts and the headrest height from time to time
and adapt them to your growing child.
1.3. Fixing with ISOFIX and Top Tether HEYNER® Capsula MultiFix ERGO 3D
and HEYNER® Capsula MultiFix AERO
1.3.1. Conditions
For fi xing with ISOFIX (I) and Top Tether (TT) there is a "semi-universal"
approval. For this reason, these seats can only be used in certain cars.
The seat has to be used with the ISOFIX fastening system (I) and the Top
Tether (TT). Based on the list of types you know, in which cars and with
which seats the HEYNER®CapsulaMultiFix ERGO 3D and the
HEYNER®Capsula MultiFix AERO can be used. The current version can be
found on www.h-germany.de.
1.3.2. Positioning on the car seat
Before you place the HEYNER ® Capsula MultiFix ERGO 3D / HEYNER®
Capsula MultiFix AERO on the car seat, fasten if necessary the two
supplied installation aids (IH) to the ISOFIX anchors (IA) in your car.
Now take the Top Tether (TT) and put it forward over the seat. Put the
HEYNER® child car seat onto the car seat in driving direction.
The ISOFIX mounting points are located between the seat and the
backrest of the car seat. Place the Top Tether (TT) over the child car
seat. Position the HEYNER®CapsulaMultiFix ERGO 3D on the car seat in
direction of travel. Check the safety indicators. These must both be red.
If the safety indicators (red) are not visible, press the green release tabs
until you hear an audible << click >>.
21
1.3.3. Installation and fi fi xing on the car seat with ISOFIX and Top
Tether
Turn the ISOFIX (IE) fi xing lever slightly upwards while pulling the two
ISOFIX terminals (IK) as far out as possible. Release the ISOFIX fi xing
lever (IE) and make sure that the two terminals do not slip back again.
Now put the two ISOFIX terminals (IK) to the ISOFIX anchors (IA) on the
car and click them into place until you hear a << click >>.
Please check with the help of the marks on BOTH SIDES, if the seat is
properly connected with the two ISOFIX anchors (IA) of the car.
GREEN: the terminal is fi xed CORRECTLY.
RED: the terminal is fi xed NOT CORRECTLY, please correct it!
Only a proper fi xing of BOTH TERMINALS guarantees the
provided hold of the seat and the protection of
your child in the car!
Now turn the fi xing lever ISOFIX (IE) slightly
L+R L+R L+R
upwards and push the seat as far as it goes
onto the seat back of the car. Let the ISOFIX
arms (IM) click into place with an audible
<< click >>.
CHECK CHEC K
English
L+R
L+R L+R L+R
CHECK
CHEC CHECK K
22
