Connecting VA-4X

Always switch off the power to each device before connecting it to your VA-4X. After
connecting your VA-4X, connect its power and then switch on the power to each device.
Front Panel
To connect the
1. Connect up to 4 HDMI sources (for example, 4K gaming sources, laptop) to the HDMI IN
Connectors (1 to 4)
2. Connect up to four HDMI acceptors (for example, display, projector) to HDMI OUT
Connectors (1 to 4)
3. Connect the power adapter to the
Figure 2).
VA-4X – Connecting VA-4X
HDMI HDMI
4K Gaming Laptop
Source
Figure 2: Connecting to the VA-4X Rear Panel
VA-4X as illustrated in the example in
on the front panel.
6
.
7
HDMI
Display
Figure
VA-4X and to the mains electricity (not shown in
Kramer Electronics Ltd.
HDMI
Projector
2:
Back Panel
5
