USER MANUAL

MODEL:
VGA Extender
P/N: 2900-300286 Rev 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VGA and is the answer not in the manual?

Questions and answers

Summary of Contents for Kramer VGA

  • Page 1: User Manual

    USER MANUAL MODEL: VGA Extender P/N: 2900-300286 Rev 2...
  • Page 2: Table Of Contents

    Switching On Adjusting the Picture Technical Specifications Figures Figure 1: VGA Extender System Figure 2: Expanded VGA Extender System Overview Figure 3: Connecting the Transmitter Figure 4 VDS Dual Screen Connections Figure 5 Line Splitter Figure 6 Detailed Connections VGA Extender – Contents...
  • Page 3: Introduction

    Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11: Sierra Products. Congratulations on purchasing your Kramer VGA Extender, which is ideal for the following typical applications: ...
  • Page 4: Getting Started

    Avoid interference from neighboring electrical appliances that may adversely influence signal quality  Position your Kramer VGA Extender away from moisture, excessive sunlight and dust This equipment is to be used only inside a building. It may only be connected to other equipment that is installed inside a building.
  • Page 5: Safety Instructions

    Kramer Electronics has made arrangements with the European Advanced Recycling Network (EARN) and will cover any costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular country go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.
  • Page 6: Overview

    Overview The VGA Extender extends video (VGA) signals up to 110m (360ft) depending on the resolution. The VGA Extender is made up of three components:  VDS transmitter  VDS dual screen receiver  Optional CAT 5 VDS line splitter...
  • Page 7: Connecting The Vga Extender System

    Connecting the VGA Extender System This section describes how to connect the VGA Extender system. Before installation:  Switch off the computer  Place cables away from fluorescent lights, air conditioners, and machines that are likely to generate electrical noise Figure 1 illustrates an overview of the VGA Extender system.
  • Page 8: Connecting The Transmitter

    Video connector Connecting the Receiver Figure 4 illustrates how to connect the VDS Dual Screen receiver: System cable to Transmitter / Line monitors Splitter VDS Dual Screen Figure 4 VDS Dual Screen Connections VGA Extender - Connecting the VGA Extender System...
  • Page 9: Connecting The Cat 5/6/7 Cable

    For the line splitter connect the supplied 12V DC power adapter. Power connector System cables SYSTEM OUT 12VDC SYSTEM IN CAT5 cable from Transmitter or previous Line Splitter Figure 5 Line Splitter VGA Extender - Connecting the VGA Extender System...
  • Page 10 Receivers or Line Splitter SYSTEM OUT Line 12VDC Computer SYSTEM IN Splitter To wall socket To wall socket CAT5 cables to Receivers or Line Splitter VDS Dual Screen Figure 6 Detailed Connections VGA Extender - Connecting the VGA Extender System...
  • Page 11: Operating The Vga Extender

    Switching On Before switching on the computer, connect the transmitter. When fully connected, the VGA Extender system is ready to transmit video signals. Adjusting the Picture To get a clear projected image, use a screwdriver to turn the picture adjuster on the VDS Dual Screen receiver unit.
  • Page 12: Technical Specifications

    Technical Specifications Transmitter Receiver INPUTS: 1 VGA on a 15-pin HD 1 twisted pair on an RJ-45 connector connector OUTPUTS: 1 twisted pair on an RJ-45 2 VGA on 15-pin HD connector connectors POWER SUPPLY: From connected computer External switching power adapter 5V DC 110/240 MAX.
  • Page 14 For the latest information on our products and a list of Kramer distributors, visit our Web site where updates to this user manual may be found. We welcome your questions, comments, and feedback. Web site: www.kramerelectronics.com E-mail: info@kramerel.com SAFETY WARNING...
