- Page 1 www.fanvil.com...
-
Page 2: Package Contents
Package Contents i16V Video Intercom Connector Mounting dimensions Unit:MM Video Intercom Quick Installation Guide Quick Installation Mounting Template Guide www.fanvil.com Screw and tool Physical specification 195 x 120 x 34 (mm) 1) Panel IR LED Camera Speaker DSS key... -
Page 3: Installation Diagram
2) Interface description Open the rear case of the device, there is a row of terminal blocks for connecting the power supply, electric lock control, etc. The connection is as follows： Serial Description Wiring port description(example above) number Ethernet interface: standard RJ45 interface, 10/100M adaptive, it is recommended to use five or five types of network cable Power interface: 12V/1A input... - Page 4 Fanvil Technology Co., Ltd Add: 4F, Block A, Building 1#, GaoXinQi Hi-Tech Park (Phase-II), 67th District, Bao'An, Shenzhen, China P.C:518101 Tel:0755-2640-2199 Fax:0755-2640-2618 Email:sales@fanvil.com...
-
Page 5: Video Intercom Configuration
IP address. (Download address http://download.fanvil.com/tool/iDoorPhoneNetworkScanner.exe) 192.168.1.128 i16V i16V Method 2: Long press DSS key for 10 seconds(after power-on for 30 seconds), and when the speaker beeps rapidly, press DSS key again quickly, the beeps stop ,the intercom will report the IP address by itself. - Page 6 Number 2: If number 1 is unavailable, it will be transferred to number 2. Line: Working line. Subtype: Speed Dial. Step 4: Set the Intercom parameters i16V Step 5: Set the security function Two short circuits input and output configuration,trigger ring,tamper detection configuration...
