Protective Cap
PosiTector UTG gages ship with a protective plastic cap over the
probe. Remove this cap prior to use. Replace it when the
instrument is not in use to protect the probe.
Wrist Strap
We recommend attaching and wearing the
supplied wrist strap.
Protective Lens Shield
The LCD is covered with a thin plastic film for protection against
fingerprints and other marks during shipment. This film, while
usually removed before using the instrument, can be left in place
to protect against paint overspray or debris. Replacements can be
purchased.
PosiTector Body
USB Port
LCD
Display
Probe
Connector
Zero Block
Medidores de espesores ultrasónicos con escáner detector de fallas o defectos UTG-C3-E POSITECTOR ADVANCED DEFELSKO manual ingles www.viaindustrial.com
UTG C probe
5 MHz Dual Element
UTG M probe
5 MHz Contact
2
2
1
