Machine Dimensions and Space Requirements

3.1 Dimensions

The following table includes the width, height, and depth dimensions (in inches and
millimeters) of the main unit and optional accessories.
Unit
*1
Main Unit
POD Deck-A1
POD Deck-A1 &
Secondary POD
Deck-A1
Paper Deck-AC1
Color Image Reader-H1
DADF-R1
Professional Puncher-B1
& Professional Puncher
Integration Unit-A1
Primary High Capacity
Stacker-C1
Secondary High
Capacity Stacker-C1
Saddle Finisher-AB2
*2
Finisher-AB1
Puncher Unit-V1
Booklet Trimmer-C1
Saddle Finisher-AB2
Booklet Trimmer-C1,
Two-Knife Booklet
Trimmer-A1, & Saddle
Finisher-AB2
Document Insertion
Unit-C1
Perfect Binder-B1
Stack Bypass-A1
*1 The Marking Engine, Fixing Unit, and Power Station Unit all make up what is hereinafter
referred to as the "Main Unit."
*2 The expansion tray is attached.
*3 The auxiliary booklet tray is attached.
*4 The Insertion Unit is included.
*5 The auxiliary tray is extended.
Version 5
Width
101.8"
38.6"
70.6"
23.7"
28.9"
25.5"
22.0"
33.9"
33.9"
*3
41.6"
35.0"
Part of the Finisher-AB1 or Saddle Finisher-AB2
*2
&
74.4"
*3
95.7"
24.6"
*4
36.3"
*5
15.7"
imagePRESS C6000 Customer Expectations Document
Depth
2,586 mm 44.7" 1,135 mm
982 mm 31.2"
1793 mm 31.2"
601 mm 24.4"
732 mm 23.5"
646 mm 22.4"
560 mm 31.2"
860 mm 30.1"
860 mm 30.1"
1,057 mm 31.2"
890 mm 31.2"
1,890 mm 31.2"
2,431 mm 31.8"
625 mm 26.3"
922 mm 31.1"
398 mm 21.4"
Height
52.4" 1,330 mm
792 mm 43.1" 1,095 mm
792 mm 43.1" 1,095 mm
621 mm 22.4"
595 mm 4.1"
570 mm 5.6"
792 mm 41.0" 1,040 mm
765 mm 48.8" 1,240 mm
765 mm 48.8" 1,240 mm
792 mm 46.5" 1,180 mm
792 mm 46.5" 1,180 mm
792 mm 46.5" 1,180 mm
792 mm 46.5" 1,180 mm
667 mm 8.4"
791 mm 53.5" 1,360 mm
544 mm 13.4"
570 mm
105 mm
143 mm
213 mm
339 mm
