CS-200 Quick User Guide
Enter the PIN code
Login
When the machine starts,
enter the PIN code:
Enter PIN code
xxxx
xxxx
Getting to know your Tax Machine
Screen Information
A1
AFF
0000005000
No services
1
A2 29.01.20
A1 Rate and services
A2 Date printed
A3 Amount
A4 Quantity (not applicable)
Shortcut keys
B1
B1 Sleep/On/Off-mode (amber/
green/flashing amber)
B2 Rate and tax services selection
B2
B3 Quantity (not applicable)
B4 Memory Job (not applicable)
B5 Credit management
B3
B4
B5
Changing the ink cartridge
1. Open the machine by pulling the left
hand side front panel towards you.
2. On the keypad, press
and select Cartridge > Headset
Replacement. The cartridge
moves to a replacement position
and a waiting message is displayed
on the screen.
Quick steps to printing your tax stamp
1
To reset the machine...
Press:
to reset default rate.
to wake the machine
up with default settings.
A3
A4
to return to the home screen.
For more specific information on your tax
machine, please visit:
kbhelp.quadient.com/cs200_ug_fee
3. Pull the blue lever to free the empty
cartridge. Remove the cartridge.
4. On the new ink cartridge, remove
the protective strip from the
printing head.
2
Select a rate:
Currently selected rate is
indicated at the
top of the screen.
AFF
No services
0000005000
29.01.20
Change rate:
1. Press
The Rate selection screen
is displayed.
AFF
0000005000
No services
AFFIDAVI T
1
Wizard
8
2. Use the keypad to choose a rate
or service option, or use the
wizard for access to more rates.
3. When done, press
to confirm your selection and
return to the home screen.
5. Insert the new ink cartridge in the
carriage, and then lock it by pushing
the blue lever back in place.
6. Close the front panel and
press on the control panel.
7. Follow the steps on screen.
3
When all steps are completed...
Print the tax stamp:
1. Insert the document into the
machine, the stamp will print on the
upper right hand side.
2. Push the document to the back and
right of the machine. Hold in position
until printing has finished, then remove.
Adding credit
Press choose 'Credit' and follow
the instructions on screen.
Note: in order to add credit to the
machine there must be funds available
in your tax account.
A0130160/B - 03/03/2020
