MRFD2N
Hydraulic diagram
Item
6
7
8
9
10
11
12
13
14
HYDAC FILTER SYSTEMS GMBH
MoWa MRFD2 3312153b en-us 2012-08-08.doc
Designation
Air-bleed valve
Inlet flange
Outlet flange
Drain valve, clean side
Drain valve, dirt side
Clogging indicator
Air-vent plug
Change-over valve
Filling ball valve
en(us)
Hydraulic diagram
BLEED
IN
OUT
DRAIN
DRAIN
Page 22 / 32
2012-08-08
