MRF 3
4. Undo the tensioning clamps between the cover
and the topmost intermediate piece with the aid
of a SW 13 mm open-end wrench.
5. Remove the cover and place it on a clean
surface.
6. Pull off both cotter pins [A] and remove the
element holding plate [B].
7. Remove all filter elements and dispose of them
in an environmentally friendly way.
HYDAC FILTER SYSTEMS GMBH
BeWa MRF3 3218003c en-us 2012-02-22.doc
en
Performing maintenance
[A] [B]
Page 23 / 32
2012-02-22
