4-163
1 Mode Showerhead
Operation & Maintenance Manual
Model Number
☐
4-163
1 Mode Showerhead
Modifications
☐
-1.5
CG
1.5 gpm (5.7 L/min) flow restrictor
☐
-2.0
2.0 gpm (7.6 L/min) flow restrictor
☐
-STN
Satin Nickel finish
Note: Append appropriate -suffix to model number.
Dimensions
A A
Note: Dimensions subject to change without notice.
Canterbury
B B
®
Specification
•
1 mode showerhead
•
2.5 gpm (9.5 L/min) standard flow restrictor
•
Showerhead shall be metal construction, plated in
standard polished chrome finish
Compliance
- ASME A112.18.1/CSA B125.1
- WaterSense 1.5 gpm & 2.0 gpm
Warranty
Limited Lifetime - to the original end purchaser in
consumer installations.
5 Years - for commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
C C
Measurements
A
1/2-14 NPT
B
3-7/8", 98 mm
C
Ø 3-7/8", 98 mm
Certi ed by
CSA Group
