Symmons Sereno 4300-TRM Installation & Operation Instructions

Trim series, trim series with ta-10 flow control spindle & t-12a cap assembly

Advertisement

Quick Links

Sereno Trim Series
Sereno Trim Series with TA-10 Flow Control Spindle & T-12A Cap Assembly
Installation & Operation Instructions
Model Numbers
TRIM ONLY
4300-TRM
Shower Valve Trim
4301-TRM
Shower Trim
4303-TRM
Hand Shower Trim
4305-TRM
Shower/Hand Shower Trim
4306-TRM
Tub/Shower/Hand Shower Trim
Compliance
ASME A112.18.1/CSA B125.1
Warranty
Limited Lifetime - to the original end purchaser in consumer/residential installations.
5 Years - for industrial/commercial installations.
Refer to www.symmons.com/warranty for complete warranty information.
Go to www.symmons.com/register to register your Symmons product.
Sereno
TRIM, TA-10, T-12A
4300TRMTC
Shower Valve Trim
4301TRMTC
Shower Trim
4303TRMTC
Hand Shower Trim
4305TRMTC
Shower/Hand Shower Trim
4306TRMTC
Tub/Shower/Hand Shower Trim
T-12A
TA-10
®
4300-TRM
4300TRMTC
4303-TRM
4303TRMTC
4301-TRM
4301TRMTC
4305-TRM
4306-TRM
4305TRMTC
4306TRMTC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sereno 4300-TRM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Symmons Sereno 4300-TRM

  • Page 1 4305TRMTC 4306TRMTC Compliance • ASME A112.18.1/CSA B125.1 Warranty Limited Lifetime - to the original end purchaser in consumer/residential installations. 5 Years - for industrial/commercial installations. Refer to www.symmons.com/warranty for complete warranty information. Go to www.symmons.com/register to register your Symmons product.
  • Page 2 1. Recommended Tools FIGURE 1 Adjustable Wrench Phillips Screwdriver Safety Glasses Thread Seal Tape 2. Dimensions Measurements FIGURE 2 Ø 2-1/4", 57 mm Ø 2-1/4", 57 mm 6", 152 mm 9-1/4", 235 mm Female 1/2" IPS thread must be recessed 7/8" from finished wall 6", 152 mm right or left 7", 178 mm 5", 127 mm...
  • Page 3 3. Parts Breakdown (Model Numbers Ending in TRMTC) Replacement Parts LIMIT STOP Item Description Part Number SCREW Cap Assy. T-12A Flow Control Spindle TA-10 IMPORTANT: Model numbers ending in TRMTC coordinate with Temptrol pressure balancing valves ordered with Test Cap. The Test Cap is used to allow pressurization of system.
  • Page 4 7. Parts Breakdown Replacement Parts FIGURE 7 Item Description Part Number Showerhead 432SH Shower Arm Flange Plug Button Screw T-251 Star Washer Handle Lock Nut T-19/20-PL Dome Cover Diverter Escutcheon Screws T-529 Mounting Plate Shower Escutcheon T-249 Screws Hand Shower 432W Cradle Mount Cradle Mount Screws...
  • Page 5 3) Install handle to shower valve. Secure with star washer, set screw and plug button (FIGURE 8.3). FIGURE 8.3 9. Installation - Diverter Valve Trim 1) Secure small mounting plate to Symmons diverter valve FIGURE 9.1 FIGURE 9.2 using mounting screws (FIGURE 9.1).
  • Page 6 11. Installation - Slide Bar Assembly 1) Press tab to remove mounting plate from cradle mount FIGURE 11.1 FIGURE 11.2 cover (FIGURE 11.1). Note: Mounting plate center tabs must be horizontal for removal. 2) Place mounting plate in position, mark and drill 3/16" holes into drywall.
  • Page 7 12. Operation (Temperature Control) 1) Turn shower handle counter-clockwise FIGURE 12.1 FIGURE 12.2 FIGURE 12.3 approximately 1/4 turn to put valve in cold position (FIGURE 12.1). 2) Turn shower handle counter- clockwise approximately 1/2 turn to put valve in warm position (FIGURE 12.2). 3) Turn shower handle counter- clockwise approximately 3/4 turn to put valve in hot position (FIGURE 12.3).
  • Page 8 For more information, go to www.P65Warnings.ca.gov. ■ ■ ■ ■ Symmons Industries, Inc. 31 Brooks Drive Braintree, MA 02184 Phone: (800) 796-6667 Fax: (800) 961-9621 ■ ■ ■ ■ Copyright © 2019 Symmons Industries, Inc. symmons.com gethelp@symmons.com ZV-3286 REV A 062819...
