4303-TRM, 4305-TRM, 4306-TRM
®
Sereno
Trim Series
Operation & Maintenance Manual
Model Numbers
4303-TRM
4305-TRM
4306-TRM
Shower
Modifications
-1.5
1.5 gpm (5.7 L/min) flow restrictor
-2.0
2.0 gpm (7.6 L/min) flow restrictor
-432HSB
30" slide bar in place of wall cradle
on hand shower units
-SS
Slip spout on any tub and shower
unit
-STN
Satin nickel finish
Note: Append appropriate -suffix to model number.
1
Hand Shower Trim
Shower Trim with Hand Shower
Tub/Shower Trim with Hand
Specifications
Tub/shower trim with hand shower and lever handle
includes wall connection, cradle for hand shower
mounting, in-line vacuum breaker, flexible metal hose,
non-diverter tub spout, 1 mode hand shower and
1 mode showerhead with standard 2.5 gpm (9.5 L/min)
flow restrictor. Shower trim with hand shower and lever
handle includes all of the above less non-diverter tub
spout. Valve trim with hand shower and lever handle
includes all of the above less non-diverter tub spout and
3 mode showerhead. Components made from metal
and nonmetallic materials plated in standard polished
chrome finish.
Warranty
Limited Lifetime - to the original end
purchaser in consumer/residential
installations.
10 Years - for commercial/industrial
installations. Refer to
www.symmons.com/warranty for
complete warranty information.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Symmons Sereno 4303-TRM
Summary of Contents for Symmons Sereno 4303-TRM
- Page 1 2.0 gpm (7.6 L/min) flow restrictor 10 Years - for commercial/industrial installations. Refer to -432HSB 30" slide bar in place of wall cradle www.symmons.com/warranty for on hand shower units complete warranty information. Slip spout on any tub and shower unit...
- Page 2 Dimensions Measurements Ø 2 1/4", 57 mm Ø 2 1/4", 57 mm 6", 152 mm 9 1/4", 235 mm Female 1/2" IPS thread must be recessed 7/8" from finished wall 6", 152 mm right or left 7", 178 mm 5", 127 mm 77", 1956 mm 4 3/4", 121 mm 5 3/4", 146 mm...
-
Page 3: Parts Breakdown
Parts Breakdown Replacement Parts Item Description Part Number Vacuum Breaker EF-104 60" Hose Wall Elbow T-444-KIT Flange Showerhead 432SH Shower Arm Flange Star Washer Handle T-251 Plug Button Set Screw Lock Nut T-19/20-PL Dome Cover Mounting Plate Mounting Screws T-529 Diverter Escutcheon Cradle Mount Cradle Mount Screws... -
Page 4: Installation
Installation Note: 4) Install shower and diverter dome 6) Install tub spout (W) to pipe fitting. Four valve body installation, please covers (L) to valves. Secure with Turn clockwise to secure. see valve body installation guides. lock nut (K). 1) Install shower escutcheon (U) to shower valve. - Page 5 Installation 9) Place mounting plate (P2) in 11) Attach cradle arm (S) and 14) Attach large end of hand shower position, mark and drill 1/8" pilot washer (R) to cradle mount (P). hose (X) to hand shower (V). holes into stud. Secure with set screw (T).
-
Page 6: Operation Temperature Control
■ ■ ■ ■ Symmons Industries, Inc. 31 Brooks Drive Braintree, MA 02184 (800)796-6667 Fax: (800)961-9621 ■ ■ ■ Copyright © 2018 Symmons Industries, Inc. www.symmons.com gethelp@symmons.com ZV-3055 REV B 011722...
