4300-TRM, 4301-TRM
Sereno
®
Trim Series
Operation & Maintenance Manual
Model Numbers
4300-TRM
4301-TRM
Modifications
-1.5
1.5 gpm (5.7 L/min) flow restrictor
-2.0
2.0 gpm (7.6 L/min) flow restrictor
-STN
Satin nickel finish
Note: Append appropriate -suffix to model number.
1
Valve Trim
Shower Trim
Specifications
Shower trim includes shower escutcheon kit and 1 mode
showerhead with standard 2.5 gpm (9.5 L/min) flow
restrictor. Valve trim includes shower escutcheon kit only.
Components made from metal and nonmetallic materials
plated in standard polished chrome finish.
Compliance
-ASME A112.18.1; CSA B125.1
WARNING: This product can expose you to chemicals
including lead, which is known to the state of California
to cause cancer, birth defects, or other reproductive
harm. For more information, go to
www.P65Warnings.ca.gov.
Warranty
Limited Lifetime - to the original end
purchaser in consumer/residential
installations.
10 Years - for commercial/industrial
installations. Refer to
www.symmons.com/warranty for
complete warranty information.
