Maintenance
Refer to Section 5.3 Maintenance Requirements in the Operators Manual for more information.
Lubricant Specifications
Grease SAE multi-purpose
Gear Lubricant SAE 85W-140
Single grade trans-hydraulic
oil recommended brands:
Petro-Canada Duratran
Hydraulic Oil
John Deere Hy-Gard J20C
Case Hy-Tran Ultraction
AGCO Power Fluid 821 XL
Grease Points
Lubrication Specs Chart
Description
High temperature extreme
pressure (EP) performance
with 1% max. Molybdenum
Disulphide (NLGI Grade 2)
lithium base
High temperature extreme
pressure (EP) performance
with 10% max. Molybdenum
Disulphide (NLGI Grade 2)
lithium base
API service class GL-5
Lubricant trans/hydraulic oil
Draper Clinic Handout - FD1 FlexDraper
Use Capacities
As required unless
otherwise specified
Driveline slip-joints
Knife drive box 2.2 liters (2.3 quarts)
Main drive gearbox 2.5 liters (2.6 quarts)
Header drive 75 liters
systems reservoir (20 US gallons)
–
–
® 9
