A/C OPERATION
OPERATING THE UNIT
Start operation by pressing OFF/ON Button.
The operation will turn on and the display panel will light up.
To stop the operation, press the OFF/ON Button again.
POWER
The unit will stop operating and the display panel light will turn off.
Please note that the OFF indication is as follows :
OFF/ON
To Start :
OFF
To Stop :
OFF
SETTING DISPLAY TEMPERATURE
Press TEMP ▲or ▼to set the display temperature.
The temperature can be set between 16 C and 30 C
Recommended temperature: 26 C ~ 28 C
NOTES:
TEMP/TIME
The latest temperature setting will be memorized and will appear
on the display the next time it's turned on.
The Display temperature selection is for display purpose only
TEMP
and shows the temperature set by you.
SELECTING OPERATION MODE
COOL
Press MODE to select the desired operation.
The indicator will light up and a "beep" sound will indicate
changing setting.
FAN
DRY
COOL mode
COOL
To set room temperature to your preference of cooling comfort.
FAN mode
FAN
To provide air circulation without cooling the room.
During Fan operation, temperature setting cannot be selected.
DRY
DRY mode
Fan motor Run at only low speed, and cannot be changed. The
MODE
comp On/Off duration is controlled by difference between room
temp and set temp.
SELECTING FAN SPEED
Press FAN SPEED to choose the speed level of the fan.
HIGH
The indicator will light up and the "beep" sound will indicate
changing setting.
FAN SPEED
MED
NOTE:
The latest fan speed setting will be memorized and the
FAN SPEED
LOW
indicator will light up the next time the unit is turned on.
ADJUSTING HORIZONTAL AIRFLOW DIRECTION
Press to select AIR SWING.
The air circulation will automatically move the
horizontal louvers left and right for better air
distribution around the room.
SWING
NOTE:
Using your hands to adjust the direction may
AIR SWING
cause the louvers to malfunction. If this
happens, stop operation immediately and restart.
O
O
O
O
Vertical
louvers
-: 11 :-
NOTE :
Vertical
adjustment
of the airflow
direction is
done manually.
