Setting
P11
P12
P16
P21
Ensure you do not change settings that are not listed in the table. Changing other
settings may cause your bike to stop working properly. If you need the default settings
for the advanced settings menu contact Lectric eBikes.
Other Display Functions
Cruise Control
Cruise control on the Lectric XP works similarly to cruise control on
a car. To activate: hold the minus button while twisting the throttle.
The bike will try to maintain a speed based on the position of the
throttle when cruise control was activated. For example, if the
throttle is twisted all the way from its resting position (to a position
that would normally maintain 20mph) and the minus button is held,
cruise control will be activated and set at 20mph. Even if the bike
is currently going slower than 20mph, the bike will try to accelerate
and maintain that speed because it was set based on that throttle
position. To cruise at low speeds, only slightly twist the throttle and
hold the minus button. Cruise control can be deactivated at any time
by pulling the brakes. This will also cut power to the motor as it would
during normal operation.
YO U R F I R S T R I D E
Function
Default
PAS
Sensitivity
PAS
Strength
Odometer
Reset
Walk Mode
Toggle
3
Sensitivity of PAS sensor. When set
to higher numbers, it will take more
crank rotations for the motor to turn
on. On lower numbers, it will take little
crank rotation to turn on the motor.
1
Strength of PAS mode. When set
to higher numbers, the motor
will come on stronger. On lower
numbers, it will be more gentle.
NA
Hold the plus button for 5 second to
reset the Odometer
1
0: Walk mode disabled
1: Walk mode enabled
Explanation
31
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the XP 2.0 and is the answer not in the manual?
Questions and answers
When I turn the key the bike does not turn on
The Lectric XP 2.0 bike may not turn on when the key is turned due to several possible issues:
1. Battery Charge: The battery may not be sufficiently charged. Ensure the battery is fully charged until the light on the charger turns green.
2. Key Position: The key might not be in the correct position. Insert the key into the battery and turn it counterclockwise to the "ON" position or until it is parallel with the frame.
3. Display Connection: There could be a connection issue with the display. Follow the cable from the display to the quick plug, unplug it with a quick pull (without twisting), inspect both sides of the plug, and reconnect it properly.
If these steps do not resolve the issue, contacting customer support is recommended.
This answer is automatically generated
I’m having a problem with unfolding the bike. I can only open the lever to a 45 degree angle. I’ve tried machine oil and WD40. It seems that the “open” button on top doesn’t work properly. **** I doing something wrong or is this a common problem?
The context does not explicitly mention a common issue where the Lectric XP 2.0 bike's lever only opens to a 45-degree angle. However, it does mention that the folding latch should be adjusted properly so that it is not too tight, allowing it to be opened when needed. If the lever does not fully open, it may be due to over-tightening or improper adjustment of the latch.
This answer is automatically generated
Is there a reset **** for the lcd
Yes, the odometer on the Lectric XP 2.0 can be reset by holding the plus button for 5 seconds. However, there is no mention of a full LCD reset option.
This answer is automatically generated
