BATTERY
OPERATING YOUR BATTERY
Your bike comes with a 48V lithium ion battery. The battery is located
inside of the front half of the folding frame. The battery compartment
can be accessed by folding the bike. The bike's battery comes with a
set of keys that are used to turn it on/off as well as keep it unlocked/
locked to the frame. Each battery has a unique set of keys. When the
battery is inside of the frame the keys can be inserted through a hole
located in the bottom of the frame. The location of this hole can be
seen in the photo below.
The battery has 3 positions: UNLOCKED, OFF, and ON. These
positions are marked on the battery and
can only be seen when the
battery is removed from the bike as shown below.
B AT T E RY
15
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the XP 2.0 and is the answer not in the manual?
Questions and answers
When I turn the key the bike does not turn on
The Lectric XP 2.0 bike may not turn on when the key is turned due to several possible issues:
1. Battery Charge: The battery may not be sufficiently charged. Ensure the battery is fully charged until the light on the charger turns green.
2. Key Position: The key might not be in the correct position. Insert the key into the battery and turn it counterclockwise to the "ON" position or until it is parallel with the frame.
3. Display Connection: There could be a connection issue with the display. Follow the cable from the display to the quick plug, unplug it with a quick pull (without twisting), inspect both sides of the plug, and reconnect it properly.
If these steps do not resolve the issue, contacting customer support is recommended.
This answer is automatically generated
I’m having a problem with unfolding the bike. I can only open the lever to a 45 degree angle. I’ve tried machine oil and WD40. It seems that the “open” button on top doesn’t work properly. **** I doing something wrong or is this a common problem?
The context does not explicitly mention a common issue where the Lectric XP 2.0 bike's lever only opens to a 45-degree angle. However, it does mention that the folding latch should be adjusted properly so that it is not too tight, allowing it to be opened when needed. If the lever does not fully open, it may be due to over-tightening or improper adjustment of the latch.
This answer is automatically generated
Is there a reset **** for the lcd
Yes, the odometer on the Lectric XP 2.0 can be reset by holding the plus button for 5 seconds. However, there is no mention of a full LCD reset option.
This answer is automatically generated
