CS-3000 RF Generator Unit Operator Manual
nContact Coagulation System Radiofrequency (RF) Generator Unit - Model CS-3000
Disclaimer
Trademarks
AtriCure, Inc.
Mason, Ohio 45040 USA
1-866-349-2342 (toll free)
1-513-755-4100 (phone)
Caution: Federal (US) law restricts this device to sale by or on the order of a physician.
AtriCure reserves the right to change its products and services at any time to incorporate the
latest technological developments. This Manual is subject to change without notice.
Although this Manual has been prepared with every precaution to ensure accuracy, AtriCure
assumes no liability for damages resulting from the application or use of this information.
nContact and the nContact logo are trademarks of AtriCure, Inc.
2797
AtriCure Incorporated
7555 Innovation Way
Customer Service:
IFU-0022.A
2021/04
IFU-0022.A
Page 1 / 12
Advertisement
Table of Contents
Related Manuals for AtriCure nContact CS-3000
Summary of Contents for AtriCure nContact CS-3000
- Page 1 Caution: Federal (US) law restricts this device to sale by or on the order of a physician. Disclaimer AtriCure reserves the right to change its products and services at any time to incorporate the latest technological developments. This Manual is subject to change without notice.
-
Page 2: Table Of Contents
Figure 19. Generator Modes, States and Operational Flow ......................11 Table 1 – List of Troubleshooting Symptoms & Actions ........................12 Chapter 7 Customer Service / Equipment Servicing/ Warranty ......................... 12 WARRANTIES ...................................... 12 Limitation on Liability ..................................12 DISCLAIMER ......................................12 AtriCure, Inc. Page 2 / 12... -
Page 3: Preface
Non-flammable agents should be used for cleaning and disinfection. Certified to US Standards Make sure the patient is not in contact to earthed metal during the oper- Radio Frequency Ablation Device, Model nContact CS-3000, rated: 100-240V~ ation of the CS-3000 RF Generator. Always use appropriate insulation 50-60Hz 250VA... -
Page 4: Guidance & Manufacturer's Declaration- Electromagnetic Immunity
GSM 1800; CDMA 1900; 1,700 – 1,990 GSM 1900; DECT; LTE Band 1, 3, 4, 25; UMTS Bluetooth, WLAN, 2,400 – 2,570 802.11 b/g/n, RFID 2450, LTE Band 7 WLAN 802.11 a/n 5,100 – 5,800 AtriCure, Inc. Page 4 / 12... -
Page 5: Glossary Of Terms
Commonly referred to as the “return electrode” or “patient electrode” or “ground pad.” Large surface area ground used to complete the circuit of the electrical current. Usually placed on the patient’s back or thigh, the Indifferent, Dispersive Electrode is connected to the generator at the Indifferent Connector. Indifferent, Dispersive Electrode AtriCure, Inc. Page 5 / 12... -
Page 6: Symbols And Icons
Measurements of resistivity are taken from mended, pre-set power settings. electrodes on a separate accessory device (not yet available) to indicate the extent of coagulation necrosis. AtriCure, Inc. Page 6 / 12... -
Page 7: System Components Supplied With The Generator
Components Not Supplied with the Generator markedly. This creates an insulating barrier. The generator rapidly decreases Power Accessories provided separately by AtriCure, Inc. for use with the CS-3000 RF if the impedance increases rapidly and terminates RF energy transmission if the Generator Unit and complying with the limits for medical devices to the IEC 60601-1 impedance increases above 500Ω. -
Page 8: Chapter 2 Setup And Operation
(black) to the receptacle on the RF generator so the pre-set Pow- er and Time values are displayed. Refer to the instruction for use of the coagulation devices for the appropriate pre-set power and time settings. AtriCure, Inc. Page 8 / 12... -
Page 9: Chapter 3 Cleaning
If soil remains on the white cloth, repeat steps 3 through 6. After cleaning is complete, turn the unit on to perform Power On Self-Test (POST). If any errors are received, contact AtriCure to begin return process. AtriCure, Inc. Page 9 / 12... -
Page 10: Chapter 5 Product Specifications
Final Percent change in impedance is displayed (↓ 20%). information. Final Power transmitted shown (50W). Refer to the Instructions for Use of the coagulation devices for the pre-set power Time at Termination of RF energy is displayed (90 s). and time. AtriCure, Inc. Page 10 / 12... -
Page 11: Warning And Fault States - Error Conditions
Time at User Termination of RF energy (34 s) displayed. contact AtriCure, Inc. for additional service and repair information When this warning occurs, an audible tone will sound three times for 1.5 seconds with 450 milliseconds between tones AtriCure, Inc. -
Page 12: Chapter 7 Customer Service / Equipment Servicing/ Warranty
AtriCure, Inc. neither assumes nor authorizes any other person to assume for it any other • Ensure the indifferent, dispersive electrode liability in connection with the sale or use of any of AtriCure Inc. products. There are no war- is attached to the patient and connected to...
