ADSL Half-Bridge Modem
Quick Start
Your ADSL half-bridge modem comes with a power cube, Ethernet cable, phone
cord, ADSL micro-filter, and software CD.
To complete the installation, you need the following:
•
An ADSL-enabled telephone wall jack to plug the half-bridge modem
into.
•
A Windows XP/2000/Me/98 computer that has an Ethernet port. This is
used to install the modem's software and to configure the modem.
When the installation is complete, the half-bridge modem will connect to an
ADSL-enabled phone jack and to a Windows computer or router.
Installing the Modem Software
1 1 1 1
Do not plug the modem into your computer or router. You need to install
the software first.
2 2 2 2
Turn on your Windows computer.
3 3 3 3
Insert the supplied CD into the CD drive of your computer. The CD should
start automatically and the Language Selection screen should appear. Select
your language. (If the CD does not start automatically, on the desktop, click
the Start button, click Run, and then type D:\setup.exe, where D is the
letter of your CD drive.)
4 4 4 4
From the Main Menu, click Installation Wizard then ADSL Half-Bridge
Modem. The software installation will begin. Follow the prompts.
5 5 5 5
When the installation is complete, click Finish then click Exit.
6 6 6 6
Remove the CD from your CD drive then shut down the computer.
Congratulations! You have installed the software. Continue with Installing the
Hardware.
Installing the Hardware
1 1 1 1
Shut down your computer.
2 2 2 2
Plug the included ADSL micro-filter into an ADSL-enabled phone jack.
Then plug the modem's phone cord from the modem's ADSL jack to the
modem jack of the micro-filter. If you'd like you can plug a phone into the
PHONE jack of the micro-filter.
3 3 3 3
Plug one end of the supplied Ethernet cable into the modem's
ETHERNET port and plug the other end into your computer's Ethernet
port.
4 4 4 4
Plug the modem's power cube into (PWR) jack and the other end into a
"live" power strip or wall outlet.
5 5 5 5
Turn the modem on with its ON/OFF button. The PWR light on the front
panel of the modem will become solid, and the LINK light will blink once.
6 6 6 6
Turn the computer on.
Congratulations! You have installed the hardware. Now continue with Getting
Connected.
