BEC 6500AEL Quick Start Manual page 4

Front Panel - LEDs / LTE Connectors
1
PORT
LTE Antenna
1
Connectors
LED STATUS
Green
Power
Red
Green
Ethernet Port
Orange
LAN 1 - 4
Blinking
USB Green
Green
Wi-Fi 2.4G / 5G
Blinking
Green
WPS
Blinking
Green
Green
Flashing
Quickly
Orange
LTE
Flashing
(Received
Quickly
Signal
Orange
Strength
Flashing
Indicator)
Slowly
Orange
Off
Green
Internet Red
Off
Screw the supplied mobile LTE antennas onto the antenna connectors on both
sides.
(6500AEL R18 / R21 uses 4 LTE antennas and 2 Wi-Fi antennas)
DESCRIPTION
System is up and ready
Boot failure
Transmission speed is at Gigabit speed (1000Mbps)
Transmission speed is at 10/100Mbps
Data being transmitted/received
Connecting to hard drive for storage or file sharing, etc.
Wireless connection to 2.4G or 5G network is established
Data being transmitted / received
Wireless device(s) being connected successfully via WPS mode
WPS is enabled and trying to establish a WPS connection
RSSI greater than -69 dBm. Excellent signal condition
RSSI from -81 to -69 dBm. Good signal condition
RSSI from -99 to -81 dBm. Fair signal condition
RSSI less than -99 dBm. Poor signal condition
No signal and the 4G_LTE module is in service
No LTE module or LTE module fails
WAN IP is received, and traffic is passing thru the device
Cannot get a WAN/public IP address
The device is either in bridged mode or WAN connection not ready.
MEANING
Quick Start Guide
