217-6327-752
VersaChassis Mini 4 Wheel Drive Assembly Instructions
Step 3: Install Clamping Shaft Collar
Slide a High Strength Clamping Shaft Collar onto the 1/4" Square shaft until it bottoms out
against the wheel. Then use a 3/32" Hex Key to tighten the shaft collar.
4X
vexpro.com
Copyright 2018, VEX Robotics Inc.
39
2018-06-15
