VersaChassis Mini 4 Wheel Drive Assembly Instructions
Step 5: Install the last #8-32 x 1.5" Star Drive Screws
Install (4x) #8-32 x 1.500" Star Drive Screws and #8-32 Nyloc Nuts in the 4 holes that were
match drilled in Step 4. These screws can be tightened all the way with the T15 Star Drive
Screwdriver.
When completed with Part 2, you will end up with an assembled
VersaChassis Mini frame.
