217-6327-752
VersaChassis Mini 4 Wheel Drive Assembly Instructions
Step 9: Install 1/4" Square Shaft
Slide the 1/4" Square Shaft into the 1/4" Square adapter.
Next, install the #10-32 set screw into the 1/4" Square adapter. Tighten the set screw until
the 1/4" Square Shaft cannot be pulled out.
Step 9 Completed
vexpro.com
Copyright 2018, VEX Robotics Inc.
28
2018-06-15
