217-6327-752
VersaChassis Mini 4 Wheel Drive Assembly Instructions
Step 2: Put Wheel on Shaft
Slide a wheel onto the 1/4" Square shaft until it bottoms out against the 1/4" Long High
Strength Shaft Spacer.
4X
vexpro.com
Copyright 2018, VEX Robotics Inc.
38
2018-06-15
