SECURING THE CHILD SEAT USING THE ISOFIX SYSTEM

Using the ISOFIX system, you can fix the CYBEX SOLUTION S i-FIX to the vehicle,
thereby increasing your child's safety. The child still needs to be secured with the three-
point belt of your vehicle.
• Insert the supplied ISOFIX guides (7) with the longer strap upwards into the
two ISOFIX fixture points (8). In some vehicles, it is better to mount the ISOFIX guides
(7) in the opposite direction.
NOTE! The ISOFIX fixture points (8) are two metallic clips for each seat and are
positioned between the backrest and the seating surface of the vehicle seat. In case of
doubt, please refer to the driver's manual of your vehicle.
• Use the ISOFIX adjustment lever (9) under the booster seat.
• Pull the two ISOFIX locking arms (5) as far as they will go.
• Now twist the ISOFIX locking arms (5) 180° so that they are facing the direction of the
ISOFIX guides (7).
NOTE! Before clicking the the ISOFIX locking arms (5) into the ISOFIX fixture points (8),
check the release buttons (10). If the green safety indicators (11) are visible, you must first
release the ISOFIX locking arms before joining by pressing and pulling back the release
button (10). Repeat the process if necessary with the second locking arm.
• Push the two locking arms (5) into the ISOFIX guides (7) until these lock into place in
the ISOFIX fixture points (8) with an audible 'click'.
• Ensure that the seat is secure by trying to pull it out of the ISOFIX guides (7).
• The green safety indicator (11) must now be clearly visible on the two grey release
buttons (10).
• You can now use the ISOFIX adjustment lever (9) under the booster seat (1) of the
CYBEX SOLUTION S i-FIX child seat to adjust the position.
• Always ensure that the entire surface of the backrest (2) of the CYBEX SOLUTION S
i-FIX is placed against the backrest of the vehicle seat.
NOTE! Note the information in the section "Placing the seat in the vehicle".
NOTE! Please use the ISOFIX guides provided to ensure that the vehicle seat is not
destroyed by the ISOFIX locking arms.
