Specifications
28
Table 8: Physical characteristics
Characteristic
Weight
1
Dimensions
Cable length, nominal
1
Does not include accessories and shipping container.
The graphs of insertion loss and return loss are as follows:
Figure 14: Insertion loss
80A03 TekConnect Probe Interface Module Instruction Manual
Description
2.04 kg (4.5 lbs)
Height: 110 mm (4.250 in)
Width: 70 mm (2.750 in)
Depth: 42 mm (1.625 in)
1 m (3.28 ft)
