PICOTE Small Grabber Value Operation & Safety Manual page 14

REPAIRING A DAMAGED CABLE - HANDLE END
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE
4. Take out the bearing and unscrew the handle from the outer casing
5. Carefully cut the outer casing. Avoid 6. Pull the wire at the Jaw end and trim the
cutting the wire inside. Cut at least 25mm inner casing to the same length as the outer
(1") or until there is no damaged wire left. casing. Approximately 5mm (0.2") of the
inner casing should be showing.
7. Push the wire back in and screw the handle back on to the outer casing. A vice helps hold it in
place.
