PICOTE Small Grabber Value Operation & Safety Manual page 11

REPAIRING DAMAGED CABLE - JAW END
SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE
8. Trim the inner casing to the same length as the outer casing. Approximately 5mm (0.2") of the inner
casing should be showing (see below). Push the wire back inside and screw the handle all the way in.
9. Screw the Jaw Head back on to the outer casing. A vice helps hold it in place.
10. Replace the spring and the wire holder.
Do not tighten the wire holder yet.
www.picoteinstitute.com
11. Put the Jaws back and tighten the Jaw
screws.
