Ultrasonic flowmeter
for high-temperature gas and superheated steam
Addendum for hazardous areas.
These additional instructions are an extension to the OPTISONIC 8300 Quick Start and
Handbook.
© KROHNE 03/2020 - 4008065001 - AD EX OPTISONIC 8300 R03
Supplementary Instructions
Supplementary Instructions
Supplementary Instructions
Supplementary Instructions
